5-4. Using the driving support systems
379
WARNING n Guide lines The tire position indicator lines and vehicle position indicator
lines may differ from actual vehicle positions depending on the number of passengers, cargo
weight, road grade, road surface conditions, brightness of the surrounding environment, whether
tires or suspension parts other than those specified are
equipped, etc. Always drive the vehicle while
confirming the safety of your surroundings.
n Under vehicle terrain view( rear side) display
lThe image displayed is one that was previously taken at a point in front of the current vehicle position. In cases such as when objects move after the image is taken, the image displayed on the screen may differ from the actual state. In addition, when driving in the dark such as at night, there are cases when obstacles cannot be confirmed from the image. lThe area covered by the camera is limited. When driving, be sure to check the vehicle’ s surroundings with your own eyes and the vehicle’ s mirrors.
Screen display and functions
When the“ X-MODE” switch is in off, the various screens display information to support several different driving situations, such as when checking for obstacles when moving forward
5
Driving
Display mode when the shift position is in P
This is a mode that displays images combined from the cameras to enable you to check obstacles around the vehicle. Images are displayed as if seen from the driver’ s seat and on an angle from above the vehicle.
Screen display 1 Shift the shift position to P.
