102 2-2. Charging
■ If a message indicating vehicle error on the DC charger side is displayed
Even if a message indicating vehicle error on the DC charger side( ex. vehicle error found, vehicle error occurred, etc.) is displayed, there is no vehicle fault but possibly a communication error between the DC charger and vehicle. In this case, there may be a terminal damage
( bad contact) in the DC charging connector. If there is no error with the vehicle,
contact the facility manager of the DC charger.
■ During DC charging
●The current charging condition can be checked on the multi-information display.
●The actual charging time may differ from that displayed on the DC charger during charging.
●There may be occasions the radio
cannot be heard due to noise occurrence during DC charging.
●As the battery approaches full charge, the charging speed will decrease and it will take longer to complete charging.
●Depending on the specifications
of the charger, charging will stop before fully charging.
●The time to complete charging may change, or charging may stop before reaching the upper
limit of the charge capacity, due to the remaining charge of the traction battery, the outside temperature, the specifications of the charger, etc.
●When DC charging using an adapter, protection functions may activate depending on the outside temperature or the usage, resulting in longer charging times, DC charging suspensions, or charging not starting.
●It is recommended to avoid frequent DC charging to prevent a decline in the traction battery capacity.
●Quickly move from the DC charging space for other users after the DC charging is completed.
●If DC charging is performed while the traction battery is extremely
cold, such as in cold weather, steam may come out of the motor compartment or dew may be
formed on the hood. This is because the heat, generated while the traction battery is
warmed, causes snow, ice, or frost to evaporate. This is not a malfunction.
●The charge amount is corrected when the traction battery is fully
charged, so 100 % remaining the traction battery may not be displayed.
■ How to set the DC charging power
You can change the DC charging power limit on the multimedia.
● Setting operations on multimedia
1 Select. 2 Select“ Vehicle customize”. 3 Select“ Charging”. 4 Select“ DC charging power”.
5 Select from“ Max”,“ 125kW”,“ 100kW”,“ 75kW”,“ 50kW”.
The maximum power when charging is limited to the selected power or less. If“ Max” is selected, the vehicle will be charged with the maximum power that can be charged.
■ Changing the“ Charging limit” settings
�P. 97
