100 2-2. Charging
■ When removing the AC charging connector
Press the release button to unlock the AC charging connector, and after making sure it is unlocked, pull the AC charging connector towards you.
If the lever does not down even if the release button is pressed, the AC charging connector is locked. In
this case, unlock the door using the smart key system or wireless remote control, and unlock the AC
charging connector.( �P. 85)
■ If the AC charging connector cannot be unlocked
�P. 86
NOTICE
■ After charging After removing the AC charging connector from the charging inlet, make sure to close the charging
port lid. If the charging port lid is left open, water or foreign objects may enter
the charging inlet, which could lead to vehicle damage.
How to use DC charging
This section explains the DC charging procedure for the traction battery.
When using a DC charger, make sure to check the operation instructions of the DC charger.
Using“ Battery Preconditioning” adjusts the traction battery temperature to the optimum state during DC charging. By keeping the traction battery at the optimum temperature, charging time can be shortened.( �P. 113)
WARNING
■ When using a DC charger Observe the following precautions.
Failure to do so may cause an unexpected accident, resulting in death or serious injury.
●Use a DC charger that complies with SAE J 3400.
●By using a conversion adapter, a DC charger that complies with SAE J 1772 can be used. Use only a conversion adapter
provided by SUBARU. When using a DC charger, follow the instructions in the manual provided with the DC charger and perform the operation safely.
●Do not use the charging cable longer than 30 meters.
