Sensaphone IMS-4000 Node for Wireless Sensors
IMS Wireless Expansion
The IMS-4000 Receiver Node for Wireless Sensors extends the
multiple communication paths between the sensors and the Receiver
environmental monitoring capability of your IMS-4000 system by
Node to ensure reliable communications. Sensors can also be battery
implementing Wireless Sensor technology. The Receiver Node can work
powered for those installations where an outlet may not be available. A
with up to 8 wireless sensors. The unit will wirelessly communicate
LCD is provided to show the status of all wireless sensors. The unit is
with the sensors, then transmit their status back to your IMS-4000 host
powered by a plug-in adapter and has a 6V 1.3 AH rechargeable backup
via its Ethernet connection. Wireless sensors are available to monitor
battery located inside the enclosure. Circuitry in the unit will maintain
Temperature, Humidity, Water on the Floor, Power, Dry Contacts, and
precise charging of the battery system.
4-20mA signals. The sensors use mesh networking technology to create
Features & Specifications
Number of Wireless Inputs
Input Types
Operating Temperature Range
Wireless Range
Wireless Sensor Frequency
Transmit Power Output
Internal Monitoring
Local Access
Power Supply
Physical
Warranty
8
IMS Wireless Solution
32° to 122°F | 0° to 50°C
Up to 250’ | 72m indoor
ISM 2.4GHz
100mW (20dBm)
AC power, battery backup
80 character backlit LCD display
Plug in power supply also monitors for power failures
Internal battery backup
7.6 x 5.1 x 2” | 190 x 130 x 50mm • 1.75lbs | .8kg
3 Years
Wireless Sensors
IMS Sensors & Accessories
The Sensaphone IMS Wireless Sensors sensors communicate with the Wireless
Node via an integrated 2.4GHz wireless radio. The devices can transmit a signal up
to 250’ | 75m indoors and even greater distances line of site. The sensors come with
3AA batteries which will power the sensors for 2 years. An optional power supply is
also available, in which case batteries function as backup power .
Product Name
Part Number
Sensaphone IMS-4000 Receiver Node for Wireless Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IMS-4200
66
