IMS Wireless Sensors
Wireless Temperature Sensor
Sensor Temperature Range
Accuracy
32° to 115°F | 0° to 57°C
± 1°F | ±.56°C
This wireless temperature sensor measures ambient air
temperatures from 32° to 115° | 0° to 57°C.
Wireless Ultra Low Temperature Sensor
Temperature Range
Accuracy
-109° to 122°F | 85° to 50°C
± 1.8°F | ±1°C
Includes an external temperature probe and is intended for
monitoring temperatures in refrigerators and freezers.
IMS Wireless Ultra Low Temperature
IMS Wireless Temperature Sensor . . . . . . . . IMS-4210 Sensor with External Probe . . . . . . . . . . . . IMS-4210-E
Wireless Humidity Sensor
Humidity Range
Accuracy
5 to 90%RH
3%
Transmits actual humidity levels to the IMS unit for
programmable high and low alarm limits.
Wireless Power Failure Sensor
Operating Range
Range
32° to 115°F | 0° to 57°C
Up to 250’ | 76m
Includes a plug in power supply that monitors for loss of
power. Runs on batteries if power does go out.
IMS Wireless Humidity Sensor . . . . . . . . . . . IMS-4211 IMS Wireless Power Failure Sensor . . . . . . . . IMS-4213
Wireless Dry Contact Bridge
Input Characteristics
Operating Range
3MΩ to 3V
32° to 115°F | 0° to 57°C
The Wireless Dry Contact Bridge provides remote contact
monitoring without running wires.
Wireless 4-20mA Bridge
Input Load
260 Ohms
Loop Current
20mA Max
The sensor provides monitoring of 4-20mA transducers. A
24V DC supply is built in to power the current loop.
IMS Wireless Dry Contact Bridge . . . . . . . . . IMS-4212 IMS Wireless 4-20mA Bridge . . . . . . . . . . . . IMS-4214
Wireless Spot Water Detection Sensor
Operating Range
5–90%
32° to 115°F | 0° to 57°C
This sensor has four probes on the bottom of the enclosure
which will trigger an alarm when any adjacent pair get wet.
Water Rope Length
Water Rope Expansion
10’ | 3m
Up to 10 ropes
This sensor comes with 10’ of leak detection cable which
triggers an alarm when it gets wet.
IMS Wireless Spot Water Detection Sensor . . IMS-4215 IMS Wireless Zone Water Detection Sensor . . IMS-4216
www.sensaphone.com
67
IMS Sensors & Accessories
Operating Humidity Range
Wireless Zone Water Detection Sensor
