IMS Infrared Motion Detection Sensor
Operating Range
Connection
Sensor Series
Dimensions
-4° to 140°F | -20° to 60°C
RJ45
IMS Solution
3.8 x 1.8 x 2.5” | 97 x 63 x 47mm
The IMS-4861 Passive Infrared Detection Sensor is a dual-element passive infrared intrusion detector for use in electronic security systems. It
reduces false alarms by eliminating background noises and nuisance stimuli. The IMS-4861 employs variable pulse-count adjustment, thus making it
adaptable for use both inside and outside of server/equipment rooms.
Part Name
Part Number
IMS Solution Infrared Motion Detection Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IMS-4861
Smoke Detection Sensor
Sensor Temperature Range
Connection
Sensor Series
Dimensions
40° to 100°F | 4° to 37°C
RJ45
IMS Solution
6.5 diameter x 2.6” | 165 x 66mm
The IMS-4862 Smoke Detector Sensor is designed to connect to the IMS Host or Node and monitor for smoke in indoor environments. The electrical
connection between the sensor and IMS is made via the attached RJ-45 patch cable. The sensor may be secured to a wall or ceiling (hardware not
included).
Part Name
Part Number
IMS Solution Smoke Detection Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IMS-4862
IMS Airflow Sensor
Operating Range
Sensing Range
Sensor Series
Dimensions
32° to 80° F | 0° to 27°C
Approximately 0 to 2,000 fpm
IMS Solution
4.2 x 1.6 x 0.9” | 106 x 40 x 23mm
Part Name
Part Number
IMS Solution Airflow Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
