Sensaphone IMS Sensors
IMS Dry Contact Bridge
Operating Range
Input
Source/Sense Voltage
Dimensions
32° to 122°F | 0° to 50°C
Normally open or normally closed dry contact
14VDC
4.2 x 3.3 x 1.3” | 106 x 84 x 33mm
The IMS-4850 Dry Contact Bridge allows you to connect a dry contact alarm from any device to your IMS. The Dry Contact Bridge is compatible with
Normally Open and Normally Closed contacts. The electrical connection between the sensor and IMS is made via RJ-45 patch cable (not included).
The sensor may be mounted either on a wall or rest on the floor.
Part Name
Part Number
IMS Solution Dry Contact Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IMS-4850
IMS 4-20mA Bridge
Current Limit
Accuracy
Sensor Series
Dimensions
50mA
± .25%
IMS Solution
4.2 x 3.3 x 1.3” | 106 x 84 x 33mm
The 4–20mA Bridge allows you to connect a 4–20mA transducer to your Sensaphone IMS unit. The 4–20mA Bridge features optical isolation between
the input and the IMS unit, which ensures trouble-free operation and safety. The electrical connection between the bridge and IMS is made via RJ-45
patch cable (not included). The bridge may be mounted either on a wall or rest on the floor.
Part Name
Part Number
IMS Solution 4-20mA Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IMS-4851
IMS Magnetic Reed Door & Window Switch
Sensor Temperature Range
Bridge Input
Source/Sense Voltage
IMS Sensors & Accessories
Sensor Series
32° to 122°F | 0° to 50°C
Normally Open or Normally Closed Dry Contact
14VDC
IMS Solution
The IMS-4860 Magnetic Reed Switch with bridge enables your IMS unit to detect if any unauthorized entry or intrusion has occurred. The bridge may
be mounted either on a wall or rest on the floor. The switch is mounted to doors or windows you wish to monitor. The electrical connection between
the bridge and IMS unit is made via RJ-45 patch cable.
Part Name
Part Number
IMS Solution Magnetic Reed Door & Window Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IMS-4860
64
