TSREH

Your Heating Specialist since 1949

TSREH Enclosure / Control Panel Heaters
Product Highlights
Prevents condensation or freezing of electronics
located within enclosures and control panels
Easy-to-install mounting plate
Air sensing thermostat for most models

Specifications:

• Heater vulcanized to an aluminum plate for easy installation
• Aluminum mounting plate has two mounting slots that are 1/4”
(6mm) by 5/32” (4mm) centered in a 1/2” (12mm) flange for
mounting
• Suggested mounting method is at the bottom of the enclosure,
mounted vertically
• 120VAC. Other voltages available upon request
• 48” (1219mm) PFA extruded leads
• Safe to operate. No exposed electrical connections
• Overall thickness (blanket and bracket): 0.140” (3.6mm) nominal;
Bracket is 0.090” (2.3mm) thick aluminum
• Exposure temperature range: -70°F to 392°F (-57°C to 200°C)
• Moisture, chemical, and radiation resistant

H E A T I N G
BLANKETS

Ordering Information:

54

Thermostat

Width*
in (mm)

Length
in (mm)

Mounting
Center
in (mm)

Total
Watts

Opens

Closes

Part Number
120VAC

2.5 (64)
2.5 (64)
2.5 (64)
2.5 (64)

6 (152)
6 (152)
6 (152)
6 (152)

4 (102)
4 (102)
4 (102)
4 (102)

60
60
60
60

without
60°F (15°C)
140°F (60°C)
180°F (82°C)

thermostat
40°F (4°C)
110°F (43°C)
150°F (65°C)

TSREH600
TSREH640
TSREH6110
TSREH6150

2.5 (64)
2.5 (64)
2.5 (64)
2.5 (64)

12 (305)
12 (305)
12 (305)
12 (305)

9 (229)
9 (229)
9 (229)
9 (229)

120
120
120
120

without
60°F (15°C)
140°F (60°C)
180°F (82°C)

thermostat
40°F (4°C)
110°F (43°C)
150°F (65°C)

TSREH1200
TSREH1240
TSREH12110
TSREH12150

* Dimensions listed are for heater and bracket; actual heater width is 1/2” (13mm) less

Other sizes and thermostat settings are available upon request
