SRMU

Your Heating Specialist since 1949

SRMU Silicone Rubber Heating Blankets
Product Highlights
Thin, our lowest profile silicone rubber blanket with
multi-stranded resistance wire
Easy-to-apply industrial strength pressure sensitive
adhesive backing option

Specifications:

• Power densities: 2.5 W/in2 (0.004 W/mm2), 5 W/in2
(0.008 W/mm2), 10 W/in2 (0.016 W/mm2)
• 120VAC single phase
• Heating element is laminated between two layers
of 20mil fiberglass reinforced silicone rubber
• Moisture, chemical, and radiation resistant
• Exposure temperature range: -60°F to 450°F
(-51°C to 232°C)
• Dielectric strength of over 2000 volts
• Silicone density 16.8 oz/yd2 (570 grams/m2) per
layer
• PFA extruded power leads: 12” (305mm)
standard length
• Ingress Protection Rating: IP54

Fiberglass reinforced silicone rubber

Ordering Information:

Standard Sizes and Wattage
Rectangular
Size

Total Watts

Width
in (mm)

Length
in (mm)

6 (152)
6 (152)

2.5 watts/in2

5 watts/in2

10 watts/in2

(.004 watts/mm2)

(.008 watts/mm2)

(.016 watts/mm2)

12 (305)

180

360

720

24 (610)

360

720

1440

36 (914)

540

1080

2160

12 (305)

360

720

1440

12 (305)

24 (610)

720

1440

N/A

12 (305)

36 (914)

1080

2160

N/A

18 (457)

18 (457)

810

1620

N/A

18 (457)

36 (914)

1620

N/A

N/A

24 (610)

24 (610)

1440

N/A

N/A

24 (610)

36 (914)

2160

N/A

N/A

Note: Plug not included

Round

Size
Diameter
in (mm)

5 watts/in2

Part Number Matrix
SRMU 02 0612 P -096
Product Series
Power Density
02- (2.5 watts/in2), 05- (5 watts/in2),
10- (10 watts/in2)
Dimensions
Rectangular, 0612- (6” x 12”)
Round, 06D- (6” diameter)
Pressure Sensitive Adhesive
P- (with), blank- (without)

Total Watts
2.5 watts/in2

Grounded heating element

10 watts/in2

(.004 watts/mm2)

(.008 watts/mm2)

(.016 watts/mm2)

6 (152)

71

140

283

12 (305)

283

565

1130

H E A T I N G
BLANKETS

6 (152)
12 (305)

3/16” (4.8 mm)

Lead Length Adjustment Option
Additional lead lengths in 6” increments example:
096- (96”), blank- (standard 12”)

Note: Plug not included

IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.
Custom Sizes and Designs Available: Contact your local distributor or BriskHeat® for more information.
