ETCHED FOIL
Your Heating Specialist since 1949
Etched Foil Heaters
Product Highlights
Ultra-thin profile
High-watt densities
Uniform heat distribution
Quick turnaround prototyping
A wide variety of options to meet your exact
requirements
Features and Options
• Any shape, cut-out, and size: up to 22” x 30” (559mm x 762mm)
• High watt densities: up to 15 watts/in2 (0.023 watts/mm2)
• Very fast thermal response time
• Thin profile: as thin as 10 mil (0.010”) (0.25mm) with PSA backing
• Tight bend radius
• Wide range of outer materials to meet your environment and application:
- Polyimide film, silicone rubber, and your choice of materials
• Wide range of attachment options:
- PSA (Pressure Sensitive Adhesive) backing, epoxies, or pre-attached to your plates and objects
• Single-zone, multi-zone, and dual-element heaters
• Integrated sensors, fuses, and control devices
• Turnkey systems with temperature control
Maximum Exposure
Temperature
Total Thickness
Advantages
Polyimide Film
392 °F (200°C)
10 mil (0.010”)
(0.25mm)
Thinnest & highest
dielectric strength
Silicone Rubber
450°F (232°C)
60 mil (0.06”)
(1.52mm)
Moisture and chemical
resistance
Other outer material options available. Contact us for more details.
Ideal For
•
•
•
•
•
•
OEM applications
Analytical instrumentation
Medical
Semiconductor
Electronics (Indoor and Outdoor)
Aerospace
H E A T I N G
BLANKETS
Outer Material
Ordering Information:
Please contact your local representative or BriskHeat®
for a quotation and personalized application assitance.
Toll Free: 800-848-7673
Phone: 614-294-3376
w w w .BriskHeat. c o m
Email: bhtsales1@briskheat.com Fax: 614-294-3807
