HTC/HWC

Your Heating Specialist since 1949

HTC and HWC Heating Cords
Product Highlights
Designed for use on small tubes, vessels, or any application
where space is limited
Can be wrapped around objects as small as 1/8” (3mm)
diameter
Exceptional flexibility
Rapid thermal response
Exceptional durability: excellent for laboratory, production,
maintenance, and R&D applications

HEATING TAPE

Specifications:
•
•

•

•

•
•

•

3/16” (4.8mm) diameter heating cord
Maximum exposure temperature:

HTC series: 900°F (482°C)

HWC series: 1400°F (760°C)
Construction:

HTC series: Double braided fiberglass outer sheath

HWC series: Double braided high temperature Samox®

fiberglass outer sheath
Power density:

HTC series: 21 W/ft (68 W/m)

HWC series: 60 W/ft (196 W/m)
Suitable for electrically conductive surfaces
2 to 6ft (0.6 to 1.8m) long power leads with

- 120VAC: Separable molded plug

- 240VAC: Crimped ferrule wire termination
Includes high-temperature tie-downs for easy installation

Ordering Information:

HTC Series: Heating Cord
Cord Length
ft
m
0.5
0.15
1
0.3
2
0.6
3
0.9
4
1.2
6
1.8
8
2.4
12
3.7

Total
Watts
17
22
43
64
82
125/135
170
260

Lead
Length
2ft (0.6m)
2ft (0.6m)
2ft (0.6m)
2ft (0.6m)
2ft (0.6m)
2ft (0.6m)
2ft (0.6m)
2ft (0.6m)

Part No.
120VAC
HTC451007
HTC451006
HTC451005
HTC451001
HTC451008
HTC451002
HTC451009
HTC451003

Part No.
240VAC
N/A
N/A
N/A
N/A
N/A
HTC452002
N/A
HTC452003

HWC Series: High Temperature Heating Cord
Cord Length
ft
m
4
1.2
6
1.8
12
3.7
18
5.5
24
7.3

Total
Watts
266
350
750/720
1000
1440

Lead
Length
2ft (0.6m)
2ft (0.6m)
6ft (1.8m)
6ft (1.8m)
6ft (1.8m)

Part Numbers
120VAC
240VAC
HWC1040
N/A
HWC1060
N/A
HWC1120
HWC2120
HWC1180
HWC2180
HWC1240
HWC2240

IMPORTANT: Temperature controller is required for these products. See pages 86 through 104 for options.
