CTL

Your Heating Specialist since 1949

XtremeFLEX® CTL Cut-To-Length Silicone Rubber Heating Tapes
Product Highlights
Well suited for pipeline tracing
Can be cut-to-length at job site
Moisture and chemical resistant
Exceptional flexibility
Ingress Protection Rating: IP54

CTL heating tape is a series heating element design; wattages and amperages vary with the tape length.
Contact BriskHeat to determine the actual wattage output for your given application.
Part
Number
CTL-A
CTL-B
CTL-C

Ohms Per
ft
(m)
0.10
(0.328)
0.90
(2.953)
10.00
(32.808)

Volts

Min
ft (m)

Max
ft (m)

120VAC
240VAC
120VAC
240VAC
120VAC
240VAC

57 (17)
114 (35)
19 (6)
38 (12)
6 (2)
12 (4)

220 (67)
440 (134)
74 (23)
146 (45)
22 (7)
44 (13)

Width
in
(mm)
1 (25)
1 (25)
1 (25)

Adhesive Tape
Provides intimate contact with surface to be heated.
A heating tape essential!
Part
Number
PSAT36A
AAT260
AAT2180

Material
Fiberglass
Aluminum
Aluminum

Width
in (mm)
0.5 (13)
2.0 (51)
2.0 (51)

Length
Yards (m)
36 (32.9)
60 (54.8)
60 (54.8)

Temperature
Limit
350°F (176°C)
350°F (176°C)
550°F (288°C)

HEATING TAPE

Ordering Information:

Available factory finished for immediate use, consult factory for details.

IMPORTANT: Temperature controller is required for these products. See pages 86 through 104 for options.

Cut-To-Length Termination Kits
CTL-LK: Lead Kit

CTL-TK: Tee Kit

• Crimp-on wire terminals
• Heavy-duty joint cover
• 8ft (2.4m) 6 AWG high temperature leads
covered with insulating sleeve
Usage: Connects main power supply to heating tape.
NOTE: Requires RTV adhesive and adhesive tape.
CTL-EK: End Kit

• Crimp-on wire terminals
• Heavy-duty joint covers
• 1ft (0.3m) 16 AWG high-temperature leads
covered with insulating sleeve
• 1 End kit
Usage: Joins three segments of heating tape.
NOTE: Requires RTV adhesive and adhesive tape.
CTL-JK: Jumper Kit

• Crimp-on wire terminals
• Heavy-duty joint cover
Usage: Terminates the end of the heating tape.
NOTE: Requires RTV adhesive and adhesive tape.
RTV3.0: RTV Adhesive
High-temperature RTV silicone adhesive sealant with
high dielectric strength. 3 oz. (89ml) tube.

• Heavy-duty joint cover
• 2ft (0.6m) 16 AWG high-temperature leads
covered with insulating sleeve
Usage: Makes a splice/jumper combining two
segments of heating tape.
NOTE: Requires RTV adhesive and adhesive tape.

Usage: Seals connection kits.
Toll Free: 800-848-7673

Phone: [phone]

w w w .BriskHeat. c o m

Email: [e-mail] Fax: [phone]

© BriskHeat Corporation. All Rights Reserved. 16-06

37
