ACCESSORIES

Your Heating Specialist since 1949

Temperature Controllers and Accessories for Heating Tapes
X2-series PID Temperature Controller Features:
• Temperature Control Range: 32°F to 1400°F
(0°C to 760°C)

-Accuracy: Type-J +/- 0.9°F (0.50°C)

Type-K +/- 0.5°F (0.25°C)
• Programmable to either °C or °F
• Type-J or Type-K thermocouple input
• 120VAC or 240VAC
• Compact, plug-and-play design
• Advanced PID control
• Simple three key user control

SDC Benchtop Temperature Controller Features:
• Small Unit Size:
- 5.5 in L x 4.25 in W x 1.75 in H
- (140 mm L x 108 mm W x 45 mm H)
• Temperature Control Range: 32°F to 999°F
(0°C to 600°C)
- Accuracy: +/- 1% FS
• Models for °F or °C display
• Choose J-type or K-type Thermocouple
Sensor
- 5-foot (1.5 m) factory installed
• 120 VAC or 240 VAC power input
• 10-Amp Fused Output

HEATING TAPE

TTD Outdoor-Use Digital On/Off Thermocouple
Temperature Controller Features:
• 120 or 240VAC
• 15 amps
• Digital On/Off controller
• Plug-in operation
• Type K thermocouple input
• Compact portable design

TS0 Portable Bulb and Capillary Temperature Controller
Features:
• 120 or 240VAC
• 15 amps
• 4 foot copper bulb and capillary
• Compact portable design
• Plug-in operation

For more information and choices, see pages 86 through 104 for the full temperature controller section.

Accessories:
Adhesive tape
Part Number

Material

PSAT36A
AAT260
AAT2180

Fiberglass
Aluminum
Aluminum

Width
in (mm)
0.5 (13)
2.0 (51)
2.0 (51)

Length
Yards
Meters
36
32.9
60
54.8
60
54.8

Temperature
Limit
350°F (176°C)
350°F (176°C)
550°F (288°C)

PSAT36A

Power Plugs
Part Number

Description

Voltage

N EMA

Amps

10115

2 Pin, 2 Wire

125VAC

1-15

15

10113

2 Pin, 3 Wire
(Grounded)

125VAC

5-15

15

10478

2 Pin, 3 Wire
(Grounded)

250VAC

6-15

15

CA0001

2 Pin, 3 Wire
(Crimp Pins Included)

Up to
600VAC

N/A

15

CA0002

2 Pin, 3 Wire
(Crimp Sockets Included)

Up to
600VAC

N/A

15
