SPEEDTRACE ROOF AND GUTTER KITS Your Heating Specialist since 1949 SpeedTrace Roof & Gutter De-Icing Kits: Self-Regulating Heating Cable Product Highlights SpeedTrace Roof & Gutter Durable, long lasting professional-grade heating cable Suitable for residential, commercial, and industrial roofing applications CABLE / WIRE Ideal for melting snow and de-icing roofs, gutters, and downspouts Prevent roof, gutter, and home damage from dangerous ice dams Prevent property damage and injuries from falling ice Easy-to-install: pre-assembled with power cord and 3-prong grounded plug Automatically adjusts heat output - NO temperature controller required! Kits includes SpeedTrace Heating Cable, Downspout Hanger Brackets, Roof Clips, UV Resistant Cable Ties, Caution Labels Additional items required, but not supplied: UV resistant RTV Sealant, Roofing Nails or Screws Specifications • • • • • • • Supply voltage: 110-120VAC, 208-277VAC* Nominal 5 W/ft (16 W/m) at 50°F (10°C); 10 W/ft (33 W/m) at 32°F (0°C) in ice and snow Minimum exposure temperature: -40°F (-40°C) Maximum exposure temperature: 150°F (65°C) Moisture and flame resistant Thermoplastic outer jacket 16 AWG bus wires 30” (76 cm) power cord with 3-prong (NEMA 5-15) plug* Measuring Heating Cable Length for Roof & Gutter De-Icing Use the equation below to calculate heating cable length: Cable Required for Roof = (R x M) + G + D (R) Roof Edge Length (linear length of roof to protect) (M) Multiplier from table below (G) Gutter Length (D) Downspout Length (X2 if heating cable returns back to gutter) Heating Cable Kit Length Required [Round Up to the nearest kit size] M = Length of Cable per Foot of Roof Edge (ft) Roof Overhang (Eave/Soffit) None 12” 24” 36” * Plug not included with 208-277VAC models (bare wire leads). Installation Requirements Suitable For: • Standard pitched roofs with or without gutters • Standard roofing materials including shingle, shake, rubber, tar, wood, metal and plastic roofs • Gutters & downspouts made from standard materials including metal and plastic Electrical Requirements: • GFCI protected circuit, local code approved outlet (power source) within close proximity to the heating cable starting point, and protected from the weather Accessories for Roof & Gutter De-Icing Part Number (120V) FFRG15-50 FFRG15-75 FFRG15-100 FFRG15-125 FFRG15-150 THERMO-CUBE Thermostatically Controlled Outlet 120VAC Aluminum Downspout Hanger Bracket SLCBL-RCLIP10 Aluminum Roof Clip (Qty 1 = 10 clips) SLCBL-RCLIP50 Aluminum Roof Clip (Qty 1 = 50 clips) Phone: [phone] Standing Seam Roof 24” Seam (M) 2.0 ft 2.4 ft 2.9 ft 3.6 ft Part Number (230V) FFRG25-50 FFRG25-75 FFRG25-100 FFRG25-125 FFRG25-150 Cable Length (feet) 50 75 100 125 150 Thermo-Cube Thermostatically Controlled Outlet • • Description SLCBL-RDOWN1 Toll Free: 800-848-7673 Standing Seam Roof 18” Seam (M) 2.5 ft 2.8 ft 3.6 ft 4.3 ft Ordering Information Not Suitable For: • Flat, slate, stone, ceramic, composite tar/gravel roofs Part Number Standard Roof (M) 2.0 ft 2.5 ft 3.0 ft 4.0 ft w w w .BriskHeat. c o m • • Power saving outlet. Thermostatically controlled outlet only runs in cold temperatures. Turns on when air temperature drops below 35°F (2°C); turns off when air temperature exceeds 45°F. Suitable for indoor/outdoor use. Email: [email protected] Fax: [phone] © BriskHeat Corporation. All Rights Reserved. 16-05 13
