INSUL-LOCK ® DS

INSUL-LOCK ® DS Flexible Closed Cell Pipe Insulation

Product Highlights

Easy-to-install with locking adhesive flap for precision fit

Double-seal technology

• Built-in pressure sensitive adhesive

• Built-in PVC overlap tape with acrylic adhesive

Your Heating Specialist since 1949

CABLE / WIRE

Scrim reinforcement on the seam surface

Environmentally-friendly, CFC-free, flexible elastomeric thermal insulation

Non-porous, fiber-free, and resistant to mold growth Resistant to moisture vapor flow Compatible with heating cable and tapes

Specifications

• Operating temperature range:-70 ° F(-57 ° C) to 220 ° F( 104 ° C)

• R-value: 3

• Color: Black

• Length: 6.0’( 1.8m)

• Thickness: 0.5”( 1.3cm)

• Density: 3 to 6 PCF

• Water vapor permeability: Dry cup( Elastomeric insulation): 0.03 perm / in Wet cup( Glued seam with overlap): 0.12 perm / in

• Water absorption %( volume change): 0

Ordering Information:

Part Number

Recommended Pipe / Tube O. D.

Inside Diameter of Insul-Lock ® DS

INSUL78 1 / 2”- 5 / 8” 7 / 8” INSUL118 3 / 4”- 7 / 8” 1-1 / 8” INSUL138 1” 1-3 / 8” INSUL158 1-1 / 8” 1-5 / 8” INSUL2 1-3 / 8” 2” INSUL218 1-5 / 8” 2-1 / 8” INSUL238 2” 2-3 / 8” INSUL258 2-1 / 8” 2-5 / 8” INSUL278 2-3 / 8” 2-7 / 8” INSUL318 2-5 / 8” 3-1 / 8” INSUL312 2-7 / 8” 3-1 / 2” INSUL358 3-1 / 8” 3-5 / 8” INSUL418 3-1 / 2” 4-1 / 8” INSUL412 4” 4-1 / 2”

Applications:

• Self-Regulating heating cable pipe / tube insulation

• Freeze protection

• Prevent condensation on refrigerant lines, cold water plumbing, roof drains, and chilled water systems

• Many indoor / outdoor uses

Recommended Accessories:

Adhesive Aluminum Tape For extra environmental protection.

Part # Width Length INSFOIL-3 3”( 76mm) 150’( 46m)

DUCK ® Duckling Duct Tape Seal spaces between multiple pieces of insulation and prevent heat loss.

Part # Width Length 282309 0.75”( 19mm) 180”( 4.5m)

14th-Edition-BriskHeat-Product-Catalog A | Page 26
