Aircraft Non-Destructive Testing( NDT) Kits continued
Specifications
COMPOSITE CURING
Temperature Controller
• Universal voltage 100-240 VAC
• Dual zone will control one individual heater, or two heaters in tandem
• Αutomatic and independent temperature control per heater
• Preset locked ramp / soak( slope) temperature
• Αccuracy ± 1 ° C( 1.8 ° F)
• End of cycle audible alarm
• Auto shut-down of heater power at end of cycle
• Differential ground fault( earth leakage) breakers
• Ground connection to elevator
• Visual or audible alarms for: ground fault, temperature limits, and thermocouple failure
• 13-minute dwell countdown timer
• Additional independent 10-minute test cycle timer, manually triggered
• Simultaneous reading of both heater blanket thermocouples
• Cycle will not start if process temperature is above 60 ° C
• Ηigh temperature process shutdown and alarm at 90 ° C
• USB port for post cycle data transfer to flash drive( USB flash disk included)
• Two-year warranty
•
• Transport container
Heating Blankets
• Sized to fit your specific aircraft elevator
• No seams; all flexible heating blankets are of a one-piece construction
• Dual voltage blankets; 110 or 220 volt
• Power density: 1400 watts / m 2( 0.9 watts / in 2)
• Two J-type thermocouples built into each blanket( 1 primary, 1 spare)
• All power and sensor wires in a single connector( plug-n-play)
• Heater blanket is very flexible and durable
• Two-year warranty
•
• Easy-to-transport storage containers included
Compact Storage Cases Fits Easily Within Luggage Compartments
Temperature Controller
Ordering Information:
Temperature Controller
Part Number |
Description |
NDTCONTROLLER |
Temperature Controller( Kit B in Airbus NDT Manual 55-20-07, 55-20- |
08, 55-20-11 |
Heating Blankets
Part Number |
Description |
300BLANKETKIT |
Airbus A300 Elevator Heating Blanket Kit( Kit A) |
320BLANKETKIT |
Airbus A320 Elevator Heating Blanket Kit( Kit A) |
340BLANKETKIT |
Airbus A340 Elevator Heating Blanket Kit( Kit A) |
Different Aircraft? |
Contact us for a solution. |
Need help sourcing a Thermographic camera? Contact us for assistance.
All Storage Cases Have Handles and Wheels for easy travel
