14th-Edition-BriskHeat-Product-Catalog A | Page 133

HOT AIR GUN

Your Heating Specialist since 1949

Hot Air Gun Curing System
Product Highlights
Ideal for small spot cures such as click studs
Includes hot air gun and temperature control
Portable, lightweight, and self-contained
Eight-segment ramp / soak control
High-limit temperature protection

Specifications:
Hot Air Gun
• Temperature factory set to 350˚F (177˚C)*
• 1500 watts, 14 cfm
• 1” to 2” (25 to 51mm) diameter cure area
• Over-temperature protection: Includes high-limit
Type-J thermcouple mounted in air stream
* Other temperatures available upon request

C O M P O S I T E
CURING

Temperature Controller
• Simple four-key user control
• Two sensor inputs (One is for control and the other
is for high-limit protection)
• Dual display shows set-point and actual
temperature
• 14 programmable alarm types
• Programmable to either ºC or ºF
• Visual and audible alarms
• Automatic tuning of PID parameters
• Accuracy ±1 least significant digit
• Ιnput voltage: 100-130VAC, 50-60Hz
• 30-amp circuit breaker
• Sensor break protection
• Auto / manual control ability
• Program security lock levels
• 6-foot (1.8m) long input power cord

Ordering Information:
Part Number

Description

BRISKAIRSP-1

Hot Air Gun Curing System

System includes...
- One Hot Air Gun
- One TTQSD-S16 Temperature Controller (with two sensor inputs)
- One 20ft Type J Thermocouple
- One 10ft Hot Gun Heater Output Cord
- One Hot Air Gun Stand
- One Storage / Carrying Case

Accessories
Part Number

Description

AIRSP-BLKKIT

Heating Blanket Upgrade Kit: Includes..
- One 8” x 8” (203mm x 203 mm) SR heating blanket
- One 10” x 10” (254mm x 254 mm) SR heating blanket
- One Power cord adapter kit
