14th-Edition-BriskHeat-Product-Catalog A | Page 131

NDT

Your Heating Specialist since 1949

Aircraft Non-Destructive Testing (NDT) Kits
Perform Moisture Intrusion Testing on Elevators and Other Aircraft Components
Product Highlights
The portable and easy heating solution for moisture
intrusion testing on elevators and other aircraft
components

• Method B in Airbus Non-Destructive Elevator

Test Manual 55-20-07, 55-20-08, 55-20-11

■ A300-600

■ A320

■ A330/340

• Your aircraft not listed? We can develop a
solution for you.
Simple-to-operate pre-programmed temperature
controller

Airbus A320 Kit Shown

Dual 110/220 volt design - No transformer required

Heating blankets designed for the shape of your
aircraft

• Durable parallel-wired heating elements

• Two-year warranty

C O M P O S I T E
CURING

Thermographic Camera Image

Easy-to-Use Full-Color Touch Screen Control

Other Features

• Single plug-n-play connector from the blanket to the controller containing all power and
sensor wiring

• Τesting data is easily saved to a USB flash drive (included)

• Easy to handle, wheeled transport and storage case

• Heater blanket strain relief is built through the entire edge of the blanket for increased
durability

• Includes six 9” (229mm) non-slip holding clamps
Toll Free: 800-848-7673

Phone: [phone]

w w w .BriskHeat. c o m

Email: [e-mail] Fax: [phone]

© BriskHeat Corporation. All Rights Reserved. 15-01

119
