SRV Composite Curing Blankets with Vacuum Seal
Product Highlights
Your Heating Specialist since 1949
Both a heater and a reusable vacuum bag
Quick, efficient, non-stress producing heat up to 450 ° F( 232 ° C)
Two-year warranty Compatible with ACR ® hot bonders and your current equipment
No Sealant Tape or Vacuum Bag Necessary!
COMPOSITE CURING
Specifications:
• Vacuum ports built into blanket eliminates the need for vacuum bagging materials
• Blanket seal added around edge eliminates the need for tacky / sealant tape
• Flexibility:- With blanket seal: 3”( 76mm) radii- Without blanket seal: 1 / 4”( 6mm) radii
• Smooth surface against repair
• Heating element laminated between two layers of nonreinforced silicone rubber, 66 mil thick with a density of 66 oz / yd2( 2237 grams / m 2)
• 450 ° F( 232 ° C) maximum exposure temperature
• Power density of 5 watts / in2( 0.008 watts / mm 2)
• Dielectric strength of over 2000 volts
• Moisture, chemical, and radiation resistant
• Strain relief built through entire edge of blanket for increased durability
• Power cord 6-foot( 1.8m) long with choice of power plug
• Ingress Protection Rating: IP54
Ordering Information:
Standard Sizes and Wattage Rectangular
|
Heated Area Blanket Size Total
Width Length Width Length
Watts in( mm) in( mm) in( mm) in( mm) 6( 152) 6( 152) 9( 229) 12( 305) 180 6( 152) 12( 305) 9( 229) 18( 457) 360 6( 152) 24( 610) 9( 229) 30( 762) 720 8( 203) 8( 203) 11( 279) 14( 356) 320 10( 254) 10( 254) 13( 330) 16( 406) 500 12( 305) 12( 305) 15( 381) 18( 457) 720 12( 305) 24( 610) 15( 381) 30( 762) 1440 16( 406) 16( 406) 19( 483) 22( 559) 1280 18( 457) 18( 457) 21( 533) 24( 610) 1620 24( 610) 24( 610) 27( 686) 30( 762) 2880
Round
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Part Number Matrix
Product Series Watt Density, 5-( 5 watts / in 2)
Voltage, 120-( 120VAC), 240-( 240VAC)
Heated Area Dimensions Rectangular, 12X12-( 12” x 12”) / Round, 12D-( 12” diameter)
Blanket Seal, S-( with Seal), Blank-( No Seal)
Power Plug See page 113 for choices
SRV 5 120 12X12 S C
IMPORTANT: Temperature controller is required for this product. BriskHeat recommends the ACR ® 3 or MiniPro ™ Hot Bonder
|
Heated Area
Diameter in( mm)
|
Blanket Size
Diameter in( mm)
|
Total
Watts
|
6( 152) |
12( 305) |
140 |
8( 203) |
14( 356) |
250 |
10( 254) |
16( 406) |
395 |
12( 305) |
18( 457) |
565 |
16( 406) |
22( 559) |
1005 |
20( 508) |
26( 660) |
1570 |
24( 610) |
30( 762) |
2270 |
114
