14th-Edition-BriskHeat-Product-Catalog A | Seite 125

SR

Your Heating Specialist since 1949

SR Composite Curing Blankets
Product Highlights
Two-year warranty
Highly flexible: ideal for leading and trailing edges
Quick, efficient, non-stress producing heat up to 450°F
(232°C)
Use on horizontal and vertical surfaces and on sharp radii
surfaces without removing the damaged section
Compatible with ACR® hot bonders and your current
equipment

Specifications:

C O M P O S I T E
CURING

• Flexibility up to 1/4” (6mm) radii
• Smooth surface against repair
• Heating element laminated between two layers of
non-reinforced silicone rubber, 66 mil thick with a density
of 66 oz/yd2 (2237 grams/m2)
• 450°F (232°C) maximum exposure temperature
• Power density of 5 watts/in2 (0.008 watts/mm2)
• Dielectric strength of over 2000 volts
• Moisture, chemical, and radiation resistant
• Strain relief built through entire edge of blanket for increased
durability
• Power cord 6-foot (1.8m) long with choice of power plug
• Ingress Protection Rating: IP54

Ordering Information:

Standard Sizes and Wattage
Rectangular
Width
in (mm)
6 (152)
6 (152)
6 (152)
8 (203)
10 (254)
12 (305)
12 (305)
16 (406)
18 (457)
24 (610)

Length
in (mm)
6 (152)
12 (305)
24 (610)
8 (203)
10 (254)
12 (305)
24 (610)
16 (406)
18 (457)
24 (610)

Total
Watts
180
360
720
320
500
720
1440
1280
1620
2880

Round
Diameter
in (mm)

Total
Watts

6 (152)
8 (203)
10 (254)

140
250
395

12 (305)
14 (356)
16 (406)

565
770
1005

SR

Part Number Matrix

5

120

06X12

C

Product Series

Watt Density, 5-(5 watts/in2)
Voltage, 120-(120VAC), 240-(240VAC)
Dimensions
Rectangular, 06X12-(6” x 12”)
Round, 12D-(12” diameter)
Power Plug
See page 113 for choices

IMPORTANT: Temperature controller is required for this product.
BriskHeat recommends the ACR® 3 or MiniPro™ Hot Bonder
Toll Free: 800-848-7673

Phone: [phone]

w w w .BriskHeat. c o m

Email: [e-mail] Fax: [phone]

© BriskHeat Corporation. All Rights Reserved. 16-06

113
