HOT BONDERS

Your Heating Specialist since 1949

ACR® MiniPRO™ Hot Bonder

Short Video

• Easiest-to-Use Hot Bonder Under 18 lbs (8kg)
▫ Fully-Loaded
▫ HD Color Touch Screen
▫ USB Data Port
▫ Small and lightweight: cure composite materials anywhere
▫ Easy-to-carry and setup: even up towers, ladders,
staircases, and on wings

• Perform Cures Faster and Better

C O M P O S I T E
CURING

▫ Single zone
▫ 8.4” (213mm) full-color touch screen
▫ Built-in vacuum venturi
▫ Universal voltage: 100-130VAC, 200-240VAC
▫ 20 amps output
▫ 10 thermocouple sensors
▫ Accepts J-type thermocouples
▫ Includes everything you need
▫ Includes training DVD

• Easy-to-Use Software on Full-Color HD Touchscreen
▫ Quick 3-step programming: Store 30 programs on hot bonder
▫ Easy-to-follow menu choices
▫ Quick data entry: Complete QWERTY keyboard interface
▫ Secure: Multiple levels of password protection
▫ Multi-task: Perform several operations at once
▫ Retains history of last 12 cures
▫ Customized post cure analysis: Data logging intervals 1 to 99
minutes
▫ Multiple langua ge support

• Fast and Simple Data Transfer with USB Drive
(USB Flash Disk Included)

▫ Transfer and archive post cure data history to your PC.
▫ Instantaneously analyze your data on your spreadsheet and

word processor programs including Microsoft® Excel® and Word®
▫ Transfer your programs quickly from one BriskHeat® bonder to

another
▫ Update your bonder easily with the latest FREE software at
www.briskheat.com
