HOT BONDERS

Your Heating Specialist since 1949

ACR® 3 Hot Bonder
Ordering Information:
The ACR® 3 Hot Bonder can be purchased either as a kit with composite curing blankets or as a base unit.
Kit with Composite Curing Blankets
Number
of Zones

Voltage

Part Number

NSN*

1

120VAC

ACR-3-S120KIT

4920-01-538-9296

1

240VAC

ACR-3-S240KIT

4920-01-538-9296

2

120VAC

ACR-3-D120KIT

4920-01-545-5200

2

240VAC

ACR-3-D240KIT

4920-01-545-5200

* Please indicate voltage when ordering with NSN.

A Kit Includes:

C O M P O S I T E
CURING

- ACR® 3 hot bonder unit
- One 10” x 10” (254 x 254mm) SR composite curing blanket per zone
- One 12” x 12” (305 x 305mm) SR composite curing blanket per zone
- One 16” x 16” (406 x 406mm) SR composite curing blanket per zone
- 10ft (3m) vacuum hoses (2 per zone)
- 10ft (3m) input power cord (1 per zone)
ACR® 3 Hot Bonder- Dual Zone
- 5ft (1.5m) heater output power cord (1 per zone)
- USB flash disk
- J-Type thermocouples (10 per zone)
- Standard connector adapters for thermocouple receptacles (10 per zone)
- Vacuum bag feed-throughs (2 per zone)
- Extra printer ribbon and paper (1 per zone)
- DVD Training Video

12” x 12” SR curing blanket
(1 per zone)

10” x 10” SR curing blanket
(1 per zone)

16” x 16” SR curing blanket
(1 per zone)

Base Unit
Number
of Zones

Voltage

Input Power Plug
NEMA Rating

Part Number

1

120VAC

L5-30P

ACR-3-S1

2

120VAC

L5-30P

ACR-3-D1

1

240VAC

L6-30P

ACR-3-S2

2

240VAC

L6-30P

ACR-3-D2
Training Video

Base Unit Includes:

- ACR® 3 hot bonder unit
- 10ft (3m) vacuum hoses (2 per zone)
- 10ft (3m) input power cord (1 per zone)
- 5ft (1.5m) heater output power cord (1 per zone)
- USB flash disk
- J-Type thermocouples (10 per zone)
- Standard connector adapters for thermocouple receptacles (10 per zone)
- Vacuum bag feed-throughs (2 per zone)
- Extra printer ribbon and paper (1 per zone)
-DVD Training Video

108

Toll Free: 800-848-7673

Phone: [phone]

w w w .BriskHeat. c o m

Available FREE online:
ACR® 3 Hot Bonder:
Demonstration and Training Video

Email: [e-mail] Fax: [phone]

© BriskHeat Corporation. All Rights Reserved. 15-02
