CENTIPEDE 2®

Your Heating Specialist since 1949

Centipede 2® Temperature Control System: PID Control Module
Product Highlights
Compact, PID-autotuned temperature controller: One
module per zone of control
Networked together with CAT 5 communication cable
NEW and STRONGER 6-pin power and RTD PT100
connection with BriskHeat® heating jackets
Power is supplied through Centipede 2® touch screen
interface

Specifications:

CONTROLLERS

• PID-autotuned control for each zone. Receives set-point through
communication link and stored in nonvolatile memory (retains settings if
power is interrupted)
• Tri-color LED status light
• NEW Bi-directional communication with modules
• Temperature sensor: RTD PT100 Platinum 100 ohm, DIN 385 curve, class B
• Maximum CAT5 communication string length: 400ft (122m) or 64 modules
• Dimensions: 2.0” x 2.2” x 1.0” (51mm x 56mm x 25mm)
• Weight: 0.14lb (65g)

Ordering Information:
Part Number
C2MOD-C

Description
Centipede 2 Module Unit. One
required for each zone of control.
®

Centipede 2® Temperature Control System:
Module Accessories
CAT5 Communication Cables
Part Number

Length

CENTCOM-001

1ft (0.3m)

CENTCOM-002

2ft (0.6m)

CENTCOM-003

3ft (0.9m)

CENTCOM-004

4ft (1.2m)

CENTCOM-005

5ft (1.5m)

CENTCOM-010

10ft (3.0m)

CENTCOM-014

14ft (4.3m)

CENTCOM-025

25ft (7.6m)

Ideal for Controlling BriskHeat® Cloth Heating Jacket Systems
