Burnishing rolls
RRA
Applications: Result:
zeus burnishing rolls are used
primarily for roller-burnishing and
supporting round material during
machining on lathes. „ „ Improved surface quality
„ „ Increased dimensional
stability
„ „ Increased hardness of
surfaces
Advantages:
RRE
„ „ Burnished workpieces exhibit
low friction and increased
resistance to corrosion after
machining
„ „ Reworking, such as grinding,
honing and lapping can
be replaced by simple
roller-burnishing machining
„ „ When used as support
rolls, they reduce wear on
the bearings and clamping
devices and minimise the
pressure on the workpiece
zeus burnishing rolls can be used in standard zeus form knurling
tools. On request, we can develop and produce a custom holding
system.
Use in this tool system is suitable for machining cylindrical work-
pieces, bores, end faces, conical workpieces and for convex and
concave outer contours.
Burnishing roll type RRA – cylindrical
Dimension [mm]
Type
RRA
Version
o
o
Ø Width Bore N 04
turned & polished, Rz 4 µm N 05
ground, Rz 2 – 3 µm N o 06
ground & polished, Rz 1 µm
10
15
20
25 4
4
8
8 4
4
6
6 


 


 



Burnishing roll type RRE – convex
Dimension [mm]
Type
RRE
40
Version
Ø Width Bore
10
15
20
25 4
4
8
8 4
4
6
6
R N o 04
turned & polished, Rz 4 µm N o 05
ground, Rz 2 – 3 µm N o 06
ground & polished, Rz 1 µm
2
2
6
6 


 


 



