Table 11 . Allowable shear loads for attachment of perimeter track to minimum ASTM A36 ( F y ≥ 36 ksi ; F u ≥ 58 ksi ) steel , lb ( kN ) 1 , 2 , 3 , 4
Fastener description
Universal knurled shank fasteners
Fastener
Shank diameter in . ( mm )
X-U 0.157 ( 4.0 )
X-U 15 0.145 ( 3.7 )
Number of |
|
|
Steel thickness ( in .) |
|
|
fasteners |
3 / 16 lb ( kN ) |
1 / 4 lb ( kN ) |
3 / 8 lb ( kN ) |
1 / 2 lb ( kN ) |
≥3 / 4 lb ( kN ) |
1 |
720 ( 3.2 ) |
720 ( 3.2 ) |
720 ( 3.2 ) |
720 ( 3.2 ) |
375 5 ( 1.7 ) |
2 1440 ( 6.4 ) 1440 ( 6.4 ) 1440 ( 6.4 ) 1440 ( 6.4 ) 750 5 ( 3.3 ) 1 395 ( 1.8 ) 395 ( 1.8 ) 450 ( 2.0 ) 500 6 ( 2.2 ) 400 6 ( 1.8 ) 2 800 ( 3.6 ) 790 ( 3.5 ) 900 ( 4.0 ) 1000 6 ( 4.5 ) 800 6 ( 3.6 )
Heavy duty 1 615 ( 2.7 ) 870 ( 3.9 ) 870 ( 3.9 ) 960 ( 4.3 ) 655 7 ( 2.9 )
EDS 0.177 ( 4.5 ) fasteners
2 1230 ( 5.5 ) 1740 ( 7.7 ) 1740 ( 7.7 ) 1920 ( 8.5 ) 1310 7 ( 5.8 ) 1 The tabulated allowable load values are for the low-velocity fasteners only , using a safety factor that is greater than or equal to 5.0 , calculated in accordance with ICC-ES AC70 . Steel members connected to the substrate
must be investigated in accordance with accepted design criteria . 2 Low-velocity fasteners shall be driven to where the point of the fastener penetrates through the steel base material , except as noted . 3 Multiple fasteners are recommended for increased reliability . 4 The minimum edge distance for fastening into steel is 1 / 2 ". Minimum spacing for fastening into steel without reduction in performance is 1 ". 5 Noted tabulated allowable load values are based upon minimum point penetration of 1 / 2 " into the steel . If 1 / 2 " point penetration into the steel is not achieved , but a point penetration of at least 3 / 8 " is obtained , the tabulated
shear load should be reduced by 8 percent . 6 Noted tabulated allowable load values are based upon minimum point penetration into the steel of 15 / 32 ". 7 Noted tabulated allowable load values are based upon a minimum point penetration into the steel of 1 / 2 ".
Figure 6 . Normal weight concrete
Figure 7 . Lightweight concrete with pour stop
Table 12 . Allowable loads for attachment of cold-formed steel deflection slip clips with X-U Universal Powder-Actuated
Fasteners 1 , 2 , 3 , 4 , 5 , 6 , 7
Clip Type 8 Fastener Number of fasteners |
Normal weight concrete allowable load 9 lb ( kN ) |
Lightweight concrete with pour stop allowable load 10 lb ( kN ) |
Location of fasteners |
Verticlip ® SLB600 ( 14 GA .) |
X-U 27 |
2 3 4 |
160 ( 0.7 ) 245 ( 1.1 ) 330 ( 1.5 ) |
|
160 ( 0.7 ) 245 ( 1.1 ) 380 ( 1.7 )
WSC 950 ( 16 GA .) X-U 27 |
2 3 4 |
125 ( 0.6 ) 145 ( 0.6 ) 220 ( 1.0 ) |
155 ( 0.7 ) 275 ( 1.2 ) 275 ( 1.2 ) |
WSC 1500 ( 12 GA .) X-U 27 |
2 3 |
90 ( 0.4 ) 185 ( 0.8 ) |
130 ( 0.6 ) 235 ( 1.1 ) |
FCSC™ ( 14 GA .) X-U 27
2 3
140 ( 0.6 ) 290 ( 1.3 )
170 ( 0.8 ) 320 ( 1.4 )
1 Testing based on deflection slip clips obtained in February 2007 . Subsequent changes by the manufacturer to the deflection slip clip design may affect load values . 2 Allowable load values are for fasteners installed in concrete having the designated compressive strength at the time of installation . 3 Allowable load values are based off of the fixtures tested . Other members connected to the deflection slip clips must be investigated in accordance with accepted design criteria . 4 Spacing of fasteners depends on the design of each deflection slip clip . Fasteners should be installed through the pre-assigned locations in the deflection slip clip . 5 For base material thickness requirements , reference Fastener Spacing , Edge Distance and Base Material Thickness Requirements for Steel in the Direct Fastening Product Technical Guide , Vol . 1 , Ed . 24 . 6 Allowable values are for loads applied perpendicular to the edge of the concrete . 7 Multiple fasteners are recommended for any attachment . 8 Verticlip is a registered trademark of The Steel Network , Inc . Fast Clip Slide Clip ( FCSC ) is a trademark of Ware 9 Allowable load based on a safety factor of 5.0 in direction shown in Figure 6 for attachment of deflection slip clip to 4000 psi Normal Weight Concrete Slab . 10 Allowable load based on a safety factor of 5.0 in direction shown in Figure 7 for attachment of deflection slip clip to 3000 psi Lightweight Concrete Slab with 12 GA . sheet steel pour stop with minimum yield strength Fy =
33 ksi .
