Table 5 . Allowable loads in structural 3000 psi lightweight concrete 1 , 2

Fastener

X-U Universal Fastener

Shank diameter in . ( mm )

0.157 ( 4.0 )

1 ( 25 ) 205 ( 0.9 ) 260 ( 1.2 ) 215 ( 1.0 ) 155 ( 0.7 ) 330 ( 1.5 ) 125 ( 0.6 ) 125 ( 0.6 ) 415 ( 1.8 ) 1-1 / 4 ( 32 ) 315 ( 1.4 ) 435 ( 1.9 ) 295 ( 1.3 ) 200 ( 0.9 ) 375 ( 1.7 ) - - - 1-1 / 2 ( 38 ) 425 ( 1.9 ) 475 ( 2.1 ) 400 ( 1.8 ) 260 ( 1.2 ) 430 ( 1.9 ) - - -

X-P 3 / 4 ( 19 ) 155 ( 0.7 ) 165 ( 0.7 ) 130 ( 0.6 ) 105 ( 0.5 ) 285 ( 1.3 ) 140 ( 0.6 ) 130 ( 0.6 ) 335 5 ( 14.9 )

Premium 1 ( 25 ) 225 ( 1.0 ) 300 ( 1.3 ) 215 ( 1.0 ) 165 ( 0.7 ) 340 ( 1.5 ) 215 ( 1.0 ) 215 ( 1.0 ) 385 5 ( 17.2 )

0.157 ( 4.0 ) Concrete

1-1 / 4 ( 32 ) 325 ( 1.4 ) 445 ( 2.0 ) 295 ( 1.3 ) 230 ( 1.0 ) 375 ( 1.7 ) - 270 ( 1.2 ) 465 5 ( 2.1 )

Fastener

1-1 / 2 ( 38 ) 425 ( 1.9 ) 480 ( 2.1 ) 400 ( 1.8 ) 330 ( 1.5 ) 365 ( 1.6 ) - - - 1 The tabulated load values are for the low-velocity fasteners only based on testing in accordance with ICC-ES AC 70 and ASTM E1190 . Allowable loads are calculated based on a safety factor of at least 5.0 . Some

conditions like high wind loads , shock or fatigue may require a different safety factor . Wood or steel members connected to the substrate must be investigated in accordance with accepted design criteria . 2 Multiple fasteners are recommended for any attachment . 3 The steel deck profile for the 3 ” deep composite floor deck has a minimum thickness of 20 gauge ( 0.0358 ”) and a minimum Fy = 33 ksi . Lower and upper flute width must be a minimum of 3-7 / 8 ”. Figure 1 in Fastener

Locations When Installing into Lightweight Concrete Over Metal Deck shows the nominal flute dimensions , fastener locations and load orientations for the deck profile . Structural lightweight concrete fill above top of steel deck must be minimum 3-1 / 4 ". 4 The steel deck profile for the 1-1 / 2 ” deep composite floor deck has a minimum thickness of 20 gauge ( 0.0358 ”) and a minimum Fy = 33 ksi . Lower flute and upper flute widths must be a minimum of 1-3 / 4 ” and 3-1 / 2 ”,

respectively . This deck may also be inverted as shown inFigure 2 in Fastener Locations When Installing into Lightweight Concrete Over Metal Deck . Figure 1 and Figure 3 in Fastener Locations When Installing into Lightweight Concrete Over Metal Deck show the nominal flute dimensions , fastener locations and load orientations for the deck profile . Structural lightweight concrete fill above top of steel deck must be minimum 2-1 / 2 ”. 5 For installation in the lower flute only .

Table 6 . Ultimate and allowable loads in concrete masonry units 1 , 2 , 3 , 4 , 5 , 6

Fastener Shank diameter in . ( mm )

Minimum embedment in . ( mm )

X-U 0.157 ( 4.0 ) 1 ( 25 )

Allowable 70 ( 0.3 ) 85 ( 0.4 ) 25 ( 0.1 ) 70 ( 0.3 )

Fastener Shank diameter in . ( mm )

Minimum embedment in . ( mm )

Load type

Tension lb ( kN )

Grout-filled CMU Face shell 7 Mortar joint 7 Top of grouted cell 9

Shear 8 lb ( kN )

Tension lb ( kN )

Shear 8 lb ( kN )

Tension lb ( kN )

Shear 8 , 10 lb ( kN )

Ultimate 1124 ( 5.0 ) 1093 ( 4.9 ) 920 ( 4.1 ) 993 ( 4.4 ) 935 ( 4.2 ) 1194 ( 5.3 ) X-U 0.157 ( 4.0 ) 1 ( 25 )

Allowable 225 ( 1.0 ) 220 ( 1.0 ) 150 ( 0.7 ) 190 ( 0.8 ) 165 ( 0.7 ) 240 ( 1.1 ) 1 The tabulated allowable and ultimate load values are for the low-velocity fasteners only based on testing in accordance with ICC-ES AC 70 and ASTM E1190 . Allowable loads are calculated based on a safety factor of at least 5.0 . Some conditions like high wind loads , shock or fatigue may require a different safety factor . 2 The tabulated allowable and ultimate load values are for low-velocity fasteners installed in normal weight or lightweight concrete masonry units conforming to ASTM C90 . 3 The tabulated allowable and ultimate load values are for low-velocity fasteners installed in concrete masonry units with mortar conforming to ASTM C270 , Type S . 4 The tabulated allowable and ultimate load values are for low-velocity fasteners installed in concrete masonry units with grout conforming to ASTM C476 . 5 The tabulated allowable and ultimate load values are for one low-velocity fastener installed in an individual masonry unit cell and at least 4 ” from the edge of the wall . 6 Multiple fasteners are recommended for any attachment . 7 Fastener can be located anywhere on the face shell or mortar joints as shown in the figure below . 8 Shear load direction can be horizontal or vertical ( Bed Joint or T-Joint ) along the CMU wall plane . 9 Fastener located in center of grouted cell installed vertically . 10 Shear load can be in any direction in the top of grouted cell application .

Shear load can be in any direction in top of grouted cell application . Concrete Masonry Unit ( CMU )
