Technical Supplement
TECHNICAL DATA
Table 1 . Ultimate loads in normal weight concrete
Fastener
X-U Universal Fastener
X-P Premium Concrete Fastener
Shank diameter in . ( mm )
0.157 ( 4.0 )
0.157 ( 4.0 )
Concrete compressive strength
Minimum embedment
2000 psi 4000 psi 6000 psi 8000 psi in . ( mm ) Tension Shear Tension Shear Tension Shear Tension Shear lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) 3 / 4 ( 19 ) 570 ( 2.5 ) 840 ( 3.7 ) 705 ( 3.1 ) 765 ( 3.4 ) 790 ( 3.5 ) 1020 ( 4.5 ) - - 1 ( 25 ) 855 ( 3.8 ) 1060 ( 4.7 ) 995 ( 4.4 ) 1380 ( 6.1 ) 1135 ( 5.1 ) 1630 ( 7.3 ) - - 1-1 / 4 ( 32 ) 1225 ( 5.5 ) 1865 ( 8.3 ) 1500 ( 6.7 ) 2020 ( 9.0 ) 1300 ( 5.8 ) 2325 ( 10.3 ) - - 1-1 / 2 ( 38 ) 1765 ( 7.9 ) 2480 ( 11.0 ) 1965 ( 8.7 ) 2250 ( 10.0 ) - - - - 3 / 4 ( 19 ) 535 ( 2.4 ) 980 ( 4.4 ) 800 ( 3.6 ) 1430 ( 6.4 ) 735 ( 3.3 ) 1575 ( 7.0 ) 875 ( 3.9 ) 1475 ( 6.6 ) 1 ( 25 ) 880 ( 3.9 ) 1395 ( 6.2 ) 1345 ( 6.0 ) 1710 ( 7.6 ) 1320 ( 5.9 ) 2040 ( 9.1 ) 1400 ( 6.2 ) 1820 ( 8.1 ) 1-1 / 4 ( 32 ) 1535 ( 6.8 ) 2060 ( 9.2 ) 1865 ( 8.3 ) 2210 ( 9.8 ) 1650 ( 7.3 ) 2350 ( 10.5 ) - - 1-1 / 2 ( 38 ) 2005 ( 8.9 ) 2280 ( 10.1 ) - - - - - -
Table 2 . Allowable loads in normal weight concrete 1 , 2
Fastener
X-U Universal Fastener
Shank diameter in . ( mm )
0.157 ( 4.0 )
Concrete compressive strength
Minimum embedment
2000 psi 4000 psi 6000 psi 8000 psi in . ( mm ) Tension Shear Tension Shear Tension Shear Tension Shear lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) lb ( kN ) 3 / 4 ( 19 ) 100 ( 0.4 ) 125 ( 0.6 ) 100 ( 0.4 ) 125 ( 0.6 ) 105 ( 0.5 ) 205 ( 0.9 ) - - 1 ( 25 ) 165 ( 0.7 ) 190 ( 0.8 ) 170 ( 0.8 ) 225 ( 1.0 ) 110 3 ( 0.5 ) 280 1 ( 1.2 ) - - 1-1 / 4 ( 32 ) 240 ( 1.1 ) 310 ( 1.4 ) 280 ( 1.2 ) 310 ( 1.4 ) 180 ( 0.8 ) 425 ( 1.9 ) - - 1-1 / 2 ( 38 ) 275 ( 1.2 ) 420 ( 1.9 ) 325 ( 1.4 ) 420 ( 1.9 ) - - - -
X-P |
|
3 / 4 ( 19 ) |
100 ( 0.4 ) |
155 ( 0.7 ) |
100 ( 0.4 ) |
175 ( 0.8 ) |
105 ( 0.5 ) |
205 ( 0.9 ) |
135 ( 0.6 ) |
205 ( 0.9 ) |
|
Premium
Concrete
|
0.157 ( 4.0 ) |
1 ( 25 )
1-1 / 4 ( 32 )
|
165 ( 0.7 )
240 ( 1.1 )
|
220 ( 1.0 )
310 ( 1.4 )
|
180 ( 0.8 )
280 ( 1.2 )
|
225 ( 1.0 )
310 ( 1.4 )
|
150 ( 0.7 )
180 ( 0.8 )
|
300 ( 1.3 )
425 ( 1.9 )
|
150 ( 0.7 )
-
|
215 ( 1.0 )
-
|
Fastener |
|
1-1 / 2 ( 38 ) |
310 ( 1.4 ) |
420 ( 1.9 ) |
- |
- |
- |
- |
- |
- |
1 The tabulated load values are for the low-velocity fasteners only based on testing in accordance with ICC-ES AC 70 and ASTM E1190 . Allowable loads are calculated based on a safety factor of at least 5.0 . Some |
conditions like high wind loads , shock or fatigue may require a different safety factor . Wood or steel members connected to the substrate must be investigated in accordance with accepted design criteria . |
2 Multiple fasteners are recommended for any attachment . |
3 This allowable load value for the X-U fastener also applies to normal weight hollow core concrete slabs with f ′ c of 6600 psi and minimum face shell thickness of 1-3 / 8 in . |
Table 3 . Ultimate and allowable loads in normal weight concrete using DX Kwik 1 , 2 , 3
Fastener
X-U 47 P8 with DX Kwik
Shank diameter in . ( mm )
Minimum embedment in . ( mm )
0.157 ( 4.0 ) 1-1 / 2 ( 38 )
Concrete compressive strength |
Load type |
4000 psi |
6000 psi |
|
Tension lb ( kN ) |
Shear lb ( kN ) |
Tension lb ( kN ) |
Shear lb ( kN ) |
Ultimate |
1973 ( 8.8 ) |
2235 ( 9.9 ) |
2101 ( 9.3 ) |
2859 ( 12.7 ) |
Allowable 395 ( 1.8 ) 405 ( 1.8 ) 360 ( 1.6 ) 570 ( 2.5 ) 1 The tabulated ultimate load values are for the low-velocity fasteners only based on testing in accordance with ICC-ES AC 70 and ASTM E1190 . Allowable loads are calculated based on a safety factor of at least 5.0 . Some
conditions like high wind loads , shock or fatigue may require a different safety factor . Wood or steel members connected to the substrate must be investigated in accordance with accepted design criteria . 2 Multiple fasteners are recommended for any attachment . 3 X-U Fastener is installed using the DX Kwik drilled pilot hole installation procedure shown in DX Kwik System .
Table 4 . Ultimate loads in structural 3000 psi lightweight concrete 1 , 2
Fastener
X-U Universal Fastener
Shank diameter in . ( mm )
0.157 ( 4.0 )
|
|
Fastener location |
Minimum embedment in . ( mm ) |
Installed into concrete
Tension lb
( kN )
Shear lb ( kN )
|
Installed through metal deck into concrete
3 inch deep composite floor deck 3
1-1 / 2 inch deep composite floor deck 4
Tension lb ( kN )
Tension lb ( kN )
Shear lb ( kN )
Shear lb ( kN )
Upper flute
Lower flute
Upper flute
Lower flute
|
3 / 4 ( 19 ) |
627 ( 2.8 ) |
747 ( 3.3 ) |
649 ( 2.9 ) |
483 ( 2.1 ) |
1235 ( 5.5 ) |
562 ( 2.5 ) |
777 ( 3.5 ) |
1862 ( 8.3 ) |
1 ( 25 ) 1037 ( 4.6 ) 1387 ( 6.2 ) 1083 ( 4.8 ) 774 ( 3.4 ) 1645 ( 7.3 ) 774 ( 3.4 ) 878 ( 3.9 ) 2079 ( 9.3 ) 1-1 / 4 ( 32 ) 1581 ( 7.0 ) 2173 ( 9.7 ) 1464 ( 6.5 ) 848 ( 3.8 ) 1885 ( 8.4 ) - - - 1-1 / 2 ( 38 ) 2116 ( 9.4 ) 2524 ( 11.2 ) 2010 ( 8.9 ) 1292 ( 5.7 ) 2155 ( 9.6 ) - - -
X-P 3 / 4 ( 19 ) 785 ( 3.5 ) 1005 ( 4.5 ) 738 ( 3.3 ) 525 ( 2.3 ) 1530 ( 6.8 ) 705 ( 3.1 ) 840 ( 3.7 ) 1680 5 ( 74.8 )
Premium 1 ( 25 ) 1245 ( 5.5 ) 1625 ( 7.2 ) 1120 ( 5.0 ) 840 ( 3.7 ) 1710 ( 7.6 ) 1310 ( 4.8 ) 1190 ( 5.3 ) 1935 5 ( 86.1 )
0.157 ( 4.0 ) Concrete
1-1 / 4 ( 32 ) 1720 ( 7.7 ) 2240 ( 10.0 ) 1985 ( 8.8 ) 1295 ( 5.8 ) 2025 ( 9.0 ) - 1430 ( 6.4 ) 2675 5 ( 11.9 )
Fastener
1-1 / 2 ( 38 ) 2260 ( 10.1 ) 2465 ( 11.0 ) 2335 ( 10.4 ) 2015 ( 9.0 ) 1835 ( 8.2 ) - - - 1 The tabulated load values are for the low-velocity fasteners only based on testing in accordance with ICC-ES AC 70 and ASTM E1190 . Allowable loads are calculated based on a safety factor of at least 5.0 . Some
conditions like high wind loads , shock or fatigue may require a different safety factor . Wood or steel members connected to the substrate must be investigated in accordance with accepted design criteria . 2 Multiple fasteners are recommended for any attachment . 3 The steel deck profile for the 3 ” deep composite floor deck has a minimum thickness of 20 gauge ( 0.0358 ”) and a minimum Fy = 33 ksi . Lower and upper flute width must be a minimum of 3-7 / 8 ”. Figure 1 in Fastener
Locations When Installing into Lightweight Concrete Over Metal Deck shows the nominal flute dimensions , fastener locations and load orientations for the deck profile . Structural lightweight concrete fill above top of steel deck must be minimum 3-1 / 4 ". 4 The steel deck profile for the 1-1 / 2 ” deep composite floor deck has a minimum thickness of 20 gauge ( 0.0358 ”) and a minimum Fy = 33 ksi . Lower flute and upper flute widths must be a minimum of 1-3 / 4 ” and 3-1 / 2 ”,
respectively . This deck may also be inverted as shown inFigure 2 in Fastener Locations When Installing into Lightweight Concrete Over Metal Deck . Figure 1 and Figure 3 in Fastener Locations When Installing into Lightweight Concrete Over Metal Deck show the nominal flute dimensions , fastener locations and load orientations for the deck profile . Structural lightweight concrete fill above top of steel deck must be minimum 2-1 / 2 ”. 5 For installation in the lower flute only .
March 2025 4
