Torque Wrenches
MADE IN USA
Electric Dial Type Torque Wrenches
• • Electric wrenches have an electric light and an audible buzzer. An
operator may elect to preset a torque value on the dial face of the
torque wrench prior to torquing.
• • Electric dial type ± 3% accuracy.
• • Battery Included
6472 - 2 Piece Handle
8471 - 2 Piece Handle
8472
8472
Grads.
English Torque
Range
Metric Grads.
Metric Length 0-600 ft. lbs. 10 ft. lbs. 0-800 Nm 20 Nm 46-1/2" 1 9-1/4
1" 0-1,000 ft. lbs. 20 ft. lbs. 0-1,400 Nm 25 Nm 74" 1 18-1/2
1" 0-2000 ft. lbs. 40 ft. lbs. 0-2,800 Nm 50 Nm 122" 5 44-1/2
Part
No. Drive
6472 3/4"
8471 8472***
Torque
Range
English
No. of Ext.
Handles
***“T” Style, 1" Dr. Female Head for use with torque multiplier. Shipped in cardboard carton.
Note: Must be used as a “T” operated by 2 people.
Torque Angle Method
The torque wrench has been the standard for tightening bolts and nuts that clamp parts
together for many years. Torque is the force used to turn a fastener nut or bolt against
friction. Friction occurs between the nut or bolt threads, fastener head and component
surface. With the many variations in squareness and stiffness of the mating parts,
clamping forces can vary significantly. The torque method also relies heavily on the
consistency of the operator.
The Torque Angle Method specifies an initial torque in conjunction with a specific
angular measurement. The initial torque mates the components. The fastener is then
rotated a specific number of degrees. If cross-threading or high-friction occur, the
fastener won’t rotate the proper number of degrees. If the fastener strips or there is low
friction, it will rotate beyond the specified number of degrees.
The Torque Angle Method takes into consideration the many variables such as flatness,
squareness of bolt heads, and surface finish that torque alone doesn’t account for. The
Torque Angle Method is commonly used in Europe, and specified by Mercedes Benz for
over 15 years on all critical fasteners.
242
www.wrighttool.com
Part No. Description
9L28100 1/2" drive
Wt.
Lbs.
