Torque Wrenches
Torque Wrenches
MADE IN USA
Dial Type Torque Wrenches
••
All dial torque wrenches are“ State-of-the-Art” torque wrenches. Exclusive torsion beam design provides long life and accuracy.
••
Exclusive bi-polar dual scales, English and Metric, permits accurate reading of both scales, with follower needle.
•• Equally accurate in both left and right hand direction.
•• Torsion drive design.
•• Large easy-to-read dial.
•• User assured of long life and reliability.
••
Accurate, ± 3 % both ways at 20-100 % of full scale.
3472
6470
Part No.
Drive
Torque Range English
Inch Pounds
Grads. English
Torque Range Metric
••
Meets and / or exceeds requirements of GGG-W-686 and / or ANSI B107.14M.
••
Calibration traceable to National Institute of Standards and Technology( NIST).
••
All wrenches shipped in plastic storage box or metal case( except 2,000 ft. lbs.), which will be shipped in a cardboard carton.
•• Follower Needle.
•• All wrenches include a“ Certificate of Calibration.”
Grads. Metric
Length
No. of Ext. Handles
2470 1 / 4 " 0-30 in. lbs.. 5 in. lbs. 0-3.5 Nm. 1 Nm 10 "— 1 2471 1 / 4 " 0-75 in. lbs. 1 in. lbs. 0-9 Nm. 2 Nm 10 "— 1 3470 3 / 8 " 0-150 in. lbs. 2 in. lbs. 0-18 Nm. 5 Nm 10 "— 1 3471 3 / 8 " 0-250 in. lbs. 5 in. lbs. 0-30 Nm. 5 Nm 10 "— 1 3472 3 / 8 " 0-600 in. lbs. 10 in. lbs. 0-70 Nm 2 Nm 14-7 / 8 "— 1-3 / 4
Foot Pounds
3473 3 / 8 " 0-50 ft. lbs. 1 ft. lbs. 0-70 Nm 2 Nm 14-7 / 8 "— 1-3 / 4 + 4470 1 / 2 " 0-175 ft. lbs. 5 ft. lbs. 0-240 Nm 5 Nm 21-1 / 2 "— 2-3 / 4 + 4471 1 / 2 " 0-250 ft. lbs. 5 ft. lbs. 0-350 Nm 10 Nm 21-1 / 2 "— 2-3 / 4 6471 3 / 4 " 0-350 ft. lbs. 10 ft. lbs. 0-480 Nm 10 Nm 27-7 / 8 "— 5-3 / 4 6470 3 / 4 " 0-600 ft. lbs. 10 ft. lbs. 0-800 Nm 20 Nm 46-1 / 2 " 1 9-1 / 4 8470 1 " 0-1,000 ft. lbs. 20 ft. lbs. 0-1,400 Nm 25 Nm 74 " 1 18-1 / 2 + New Rubber Handle
Wt. Lbs.
TORQUE WRENCHES & TOOLS
www. wrighttool. com
241
