Choke Valves
Largest choke valves ever,
destined for North Sea
The largest choke valves ever produced have been delivered to an unmanned production platform in the North Sea.
Text & image by IMI
IMI has successfully delivered what are believed to be the largest production choke valves ever manufactured to a landmark unmanned processing platform in the North Sea. The 100D DRAG ® multi-stage, multi-turn control valves, manufactured at the company’ s IMI CCI production facility in Austria, measure 20” x 20” and are rated to ASME 4500. With a design pressure of 686 barg, the valve body and bonnet comprise of forged ASTM A182 F22 Cl, while a full internal Inconel 625 weld overlay offers enhanced corrosion resistance. Leveraging the patented DRAG™ technology, the trim is made from solid tungsten carbide to provide extreme durability in high-pressure, erosive service. Following the successful completion of factory acceptance testing in Austria, three 100D DRAG ® valves have now been delivered to the site.
Unique operational challenge
Ronald Simon, Principal Engineer for Oil & Gas, and Valve Doctor, at IMI, said:“ The successful production and delivery of the 100D DRAG ® valves underscores our capability to provide cutting-edge flow control solutions for highpressure, high-flow offshore applications.“ Designed for use within an unmanned offshore platform, which itself presents a unique operational challenge, these valves are built to the highest quality standards, which are essential to ensuring reliable, safe, and efficient production in remote environments.”
Mr Simon added:“ Ultimately, this delivery marks a significant engineering milestone for IMI and reaffirms our commitment to supplying industry-leading flow control solutions for the most demanding offshore applications.” www. valve-world. net Valve World November 2025
