PRODUCTS
targets KTV market with Soundbar
delivering linear excursion
of 22mm/pp at consistent
magnetic force. Three aluminium
shorting rings are
also included to reduce intermodulation distortion; minimising
induction variation whilst reducing
thermal compression.
The left and right channels are
served by double 8-inch/1.75inch coaxial drivers, with the
8-inch cone covering the 200Hz to
1.8kHz range and the HF drivers
covering 1.6kHz to 20kHz. While
the Soundbar is intended for near-
required.
Also new from the manufacturer
is the U4, a double 18-inch
subwoofer described as offering
‘immense headroom’ and
designed to work exclusively with
integrated solution for DSP control,
control and diagnostics. It is being
aimed at nightclub installs as
well as more general mobile and
installation applications.
Inside the enclosure, a 32mm
high, 4-inch voice coil reportedly
delivers an excursion of 20 mm/
pp at consistent magnetic force.
The assembly also boasts a
aluminium shorting rings to
reduce intermodulation distortion.
According to the manufacturer, the
U4 is an ideal sub-extension to for
its G-Series, D-Series, CUE-Series
and TiRAY systems, extending the
system performance down to 30Hz.
Shipping: Now
Web: www.codaaudio.com
back functions. Current speaker
models include the in-ceiling
IP-CM52-BGM, IP-CM52s-BGM,
IP-CM62-BGM and IP-CM82-BGM,
and the surface-mount IP-SM500i-II.
By utilising CobraNet, the system
allows each SoundTube speaker
on the network to be powered via
its Ethernet cable and individually
set up and equalised. Each
3/4 Island
The IP CM52 BGM
speaker can receive different
audio signals and is continuously
monitored by the system to
provide report-back status to the
main control point. Any failure
in the speaker will immediately
trigger an alarm, and the system
e-mail message to an installer
away from their position. The
system is also compatible with all
other CobraNet-enabled control
systems, and multiple SoundTube
switches may be linked for large
speaker systems.
In addition to the 16 Ethernet
ports, the STNet-Switch includes
two gigabit ports.
Shipping: Now
Web: www.soundtube.com
L-ACOUSTICS is pleased to announce the arrival of our new baby coaxial enclosure. Height: 6.5 inches. Weight: 7.7 pounds. It
delivers plenty of SPL for your fills and distributed sound in rentals or in fixed installations. The XT family traits are pronounced:
studio monitor sonic performance, remarkable presence, clarity, smooth radiation pattern, constant tonal balance over distance and
high feedback immunity. Together the 5XT, 8XT, 12XT, and 115XTHiQ are the party of four that offers you a palette of formats,
directivities and SPL options. All with easy integration, maximum flexibility, quick and easy mounting, advanced amplification,
monitoring, control and SOUNDVISION modeling software, it’s no wonder the clan is growing.
More at www.l-acoustics.com
July–August 2014 PRO AUDIO ASIA 69
