Martin Audio expands Differential Directivity systems
Martin Audio’s DD12, the latest addition to the company’s
Differential Directivity Series
COMBINING STATE-OF-THE-ART
transducers with Differential
Dispersion horn technology and
Class-D ampli cation, the multipurpose DD12 loudspeaker forms
the latest addition to Martin Audio’s
comprehensive range.
According to the manufacturer,
its patented rotatable Differential
Dispersion technology delivers a
more consistent coverage than
traditional X x Y horns. The two-way
powered speakers also feature
onboard DSP, a switched mode
power supply with Power Factor
Correction (PFC), and internal
memory allowing for factory ‘plugand-play’ or user-generated DSP
preset snapshots to be recalled via
a selector switch on the rear panel.
Whether con gured as an element
in a stand-alone system or part
of a larger MLA/MLA Compact
system, individual DD12’s can be
controlled and monitored from a
laptop or wireless tablet PC via the
manufacturer’s VU-NET proprietary
software. Connections to PCs can
be made directly via USB, or via
Martin Audio’s U-NET network and
Merlin loudspeaker and network
management system.
The cabinet supports surface,
ceiling and pole mounting, and has
a universal tilting bracket, making it
suitable as a PA in small-to-medium
installations.
As well as the DD12, Martin has
also released the 15-inch selfpowered PSX subwoofer. Intended
as a companion for the DD6, XD12
and XD15 loudspeaker systems, it
comprises a 4-inch voice coil, longexcursion driver in a re ex-ported
The Martin Audio PSX sub
enclosure. It houses two channels of
Class-D ampli cation – one channel
for itself and one channel to power
an XD12, an XD15, or up to three
DD6s.
Producing a total peak output of
2,400W – with 1,400W allocated to
the sub and the remaining 1,000W
to drive the associated system – the
operating range of the PSX is 48 to
150Hz with a peak SPL capability of
136dB at 1m.
Onboard DSP performs delay,
crossover and EQ functions, while
like the DD12, the sub and its fullrange system can all be controlled
and monitored via VU-NET software.
The speaker housing is made
from tour-grade plywood coated in
hard-wearing polyurethane with a
Declon backed steel grille protecting
the cone. Practical features include
a pole-mount tting on the top
surface, bar handles and protective
skids. When stacked, the skids on
the base of the enclosure align with
recesses in the top of the enclosure
below.
Shipping: Now
Web: www.martin-audio.com
Cost effective addition to JBL Precision Directivity range
INTRODUCED AS a cost effective
addition to the Precision Directivity
range of loudspeakers from JBL
Professional, the PD6000 series
is aimed at midsize to large
venues, sitting between the larger
PD700 and more compact AE
Seri es systems. The 14-strong
range leads a number of launches
from the Harman Professional
brand, including Commercial
Series ampli ers and mixers, and
the LSR310S powered studio
subwoofer.
The PD6000 series is con gurable
either individually or as an
array and intended for stadia,
JBL has added the PD6000 series to its Precision Directivity range
arenas, performing arts facilities,
auditoriums, houses of worship and
dance clubs. It includes four threelow-frequency drivers feature
per-channel CSA280Z, and the
way full-range systems, four 12-inch Vented Gap Cooling (VGC). All of
40W per-channel CSA240Z. Three
two-way systems, four two-way midthe PD6000 models are available
more single-channel ampli ers are
high systems and two low-frequency in white as well as WRC and WRX
also available in the shape of the
models. Coverage patterns include
weather-resistant
120W CSA1120Z, 80W
the original 40 x 30, 60 x 40, and
versions for
CSA180Z, and the
90 x 50, plus an additional new
pattern of 60 x 60.
Arguably the key to making
the series more affordable is
its newly-introduced injectionmoulded rotatable Progressive
Transition (PT) waveguides. The
JBL’s CSM 14 and CSM 28 commercial mixers
technology has been applied to
both the mid-frequency 24-inch
installation in moderate to extreme
40W CSA140Z. In terms of mixers,
x 24-inch waveguide and its 12
outdoor environments.
two options have been announced
x 12 HF equivalent. In addition,
Elsewhere, JBL Commercial has
– the CSM-28 offering eight inputs
all compression drivers in the
debuted six Commercial Series
and two outputs, and the CSM-14
series have been upgraded to
ampli ers and two Commercial
mixer offering four inputs and one
utilise CMCD-82H cone midrange
Series mixers.
output.
compression driver, which includes
Included are three two-channel
All of the ampli ers are 1U
the manufacturer’s Differential
ampli ers comprising the 120W
in height and half a rack wide,
Drive technology. Similarly, all
per-channel CSA2120Z, the 80W
incorporate Harman’s DriveCore
54 PRO AUDIO ASIA July–August 2014
ampli er IC technology, and can
operate into 8-ohm and 4-ohm
loads whilst operating with both
70V and 100V distributed audio
systems without the need for
a separate transformer. They
also include a universal power
supply and accept an Ethernet
control cable for use with the
manufacturer’s CSR-V wall-mount
volume control.
The mixers are described as
‘perfect for background music,
paging, and security’, boast minimal
front-panel control and rear-panel
RCA inputs plus Euro-block mic/line
input and output connectors. Other
features include priority muting,
VOX ducking and mic phantom
power.
Moving from the installation sector
to the studio market, the LSR310S
powered subwoofer is intended
for recording and postproduction
applications, having been optimised
for use with JBL’s 3 Series monitors.
The LSR310S is described as
completing the 3 Series, extending
its low-frequency response into
the 20Hz range. It is driven by
a 200W Class-D ampli er and
incorporates a 10-inch highexcursion woofer working alongside
the manufacturer’s patented Slip
Stream Port to deliver LF response
below 27Hz, with a peak output
of 113dB SPL. It also boasts
a selectable XLF extended low
frequency setting that emulates the
augmented low frequency response
heard in a dance club environment.
Other features include balanced
XLR and ¼-inch inputs, a selectable
input sensitivity switch and three
crossover settings – ‘80Hz’ (which
implements high and low pass
lters), ‘XLF’ and ‘External’ (which
bypasses all ltering, allowing the
use of an external crossover).
Finally, the manufacturer has
introduced the VRX Line Array
The LSR310S subwoofer from JBL
Calculator as a design tool for its
VRX Constant Curvature Series.
Up to four audience planes can be
modelled on the software including
features such as ground-level
seating, multiple balconies, stage
areas and rear wall boundaries. In
addition, an ‘array con guration’
page is included to show the size,
weight, and rigging parameters with
built-in working load limit safety
warnings. The software is available
for download now.
Shipping: Now
Web: www.jblpro.com
