LU7
Specifications (Base)
LU7 Base Units
LU7-02S
Model
LU7-02
LU7-02FB
LU7-02M2
LU7-02M2FB
DC 24V
AC 90 to 250V (50/60Hz)
Rated Voltage
Operating Voltage Range
Alarm
Short Body
AC 100 to 240V (50/60Hz)
DC 21.6 - 26.4V
Unit Color Variation
—
Buzzer 1*
Buzzer 2**
—
Buzzer 1*
Ivory White
Silver
Black
LU7-02SU
LU7-02SK
Buzzer 2**
Current Consumption
—
50±10mA
24±10mA
—
50±10mA
24±10mA
Power Consumption
—
1.2±0.25W 0.58±0.25W
—
1.8±0.25W
1.3±0.25W
Sound Level
—
Max: 90±5dB (at 1m)
Min: 70dB or less (at 1m)
—
Max: 90±5dB (at 1m)
Min: 70dB or less (at 1m)
Flash Cycle
—
60±12 flashes per minute
—
-300C to +600C
Operating Temperature Range
LU7-02S
Standard Body
60±12 flashes per minute
-250C to +550C
Upright, Indoor Only
Mounting Direction
IP65 (IP66 with Cable Gland***)
Protection Rating
150g
Mass (±10%)
280g
250g
310g
PNP/NPN
Open Collector
340g
NPN
LU7-02/M2
*Buzzer 1: Continuous **Buzzer 2: Intermittent ***Cable Gland to be supplied by user
LU7-02U/M2U
LU7-02K/M2K
Specifications (Module)
LU7 LED Units*
Model
Unit /LED Color
Rated Voltage
Operating Voltage Range
Current/Power Consumption
Operating Temperature Range
Mass (±10%)
LU7-E-R
LED Unit Red
LU7-E-Y
LED Unit Amber
52mA/1.25W
LU7-E-G
LU7-E-B
LED Unit Green
LED Unit Blue
DC 24V
DC 21.6 - 26.4V
42mA/1.0W
-300C to +600C
60g
LU7-E-C
LED Unit White/Clear
*Operates on LU7-02, LU7-02FB, LU7-M2 and LU7-M2FB Base Units
Dimensions
LU7
Standard Body
Wiring
LU7-02S
Short Body
External Contact Capacity
Specifications
LED Unit Current Consumption
(1 Unit) Contact Capacity
Current Consumption
Alarm
Inrush Current
Contact Capacity
Current Consumption
Power
Supply Contact Capacity
(Unit: mm)
70
Height
1 Tier : 118
2 Tiers : 159
3 Tiers : 200
4 Tiers : 241
5 Tiers : 282
70
Height
Height
Height
1 Tier : 211
2 Tiers : 252
3 Tiers : 293
4 Tiers : 334
5 Tiers : 375
External Contact Fuse
Voltage
All Models
Mounting Dimensions
Nameplate
Wire Hole
14
Mounting
Hole 3- 4
Front (Buzzer)
94
DC 24V
AC 100 - 240V
Red,Amber: 52mA Green,Blue,White/Clear: 42mA
Is≥100mA, Vs≥AC 35V
50mA
100mA
Is≥100mA, Vs≥AC 35V
40mA (250VAC) - 110mA (90VAC)
360mA
Is≥500mA
9A (90V) - 25A (250V)
Vs≥AC 35V
Vs≥AC 250V
Fuse Amperage Rating
250V, 1A
