Modular Design
With a modular design, freely configuring and assembling a
Signal Tower is easy and the modules can be put away for when
the machine has to be shipped to reduce shipping costs and
shipping crate material.
LU7
THE
LU7 Series
Advantage
70mm diameter
Innovative LED Modular Style Signal Tower
Ultra-bright LEDs combined with an
Innovative prism-cut lens design
With the innovative prism-cut lens, a small diameter can
emit enough light to be seen from great distances while
reducing costs of the Signal Tower.
Modular Construction
Color-coded & spring-loaded Terminal Block
Easier wiring and more reliable in comparison to screw-type
connections with each terminal block color corresponding to the
LED module color.
Wiring Terminals
Ultra-bright LED
O-rings
Two selectable alarms integrated in
the Base Module
The O-rings seal the tower from liquids so that an IP-65 rating can
be achieved to allow the tower to be used in wet environments.
Adding sound to a visual signal enhances the critical
nature of the status, bringing more attention to certain
conditions while still allowing up to five LED modules to
be used because the alarms are built into the base.
ones
lectable T
2 Se
IP65 Protection
IP65 & IP66 with Optional Cable Gland
ADJUSTABLE VOLUME
The new LU7 is designed to add a cable gland so that a rating of
IP-65 can be achieved to be used in harsher environments.
(Cable Gland is to be supplied
Cable Gland
by the user.)
ew
N
Delivers Sound of up to 90 dB (at 1m)
Alarm can be easily heard over ambient noises.
