Playback Modes
Despite its slim appearance, it is able to produce a maximum of 87dB (at 1m).
(Actual sound level will depend on sound type and surrounding operating conditions.)
Several playback modes for a combination of applications.
Plays back up to 5 messages using Channels
1 to 5.
A Bit Input Mode
B
BKV
Up to 95dB (at 1m)
Mode Selector Switch
Plays back up to 31 messages using
Channels 1 to 5.
Binary Input
Mode
Plays back up to 4 messages using Channels
Bit Input/
1 to 4. When Channel 5 receives an input,
C Volume
Reduction Mode the volume is reduced by about -15dB.
Plays back up to 15 messages using
Binary Input/
Channels 1 to 4. When Channel 5 receives
D Volume
an input, the volume is reduced by about
Reduction Mode
-15dB.
Plays back up to 5 messages using Channels
1 to 5. If a message input occurs during
Bit Input/
E Priority Message playback of another message, the message
Playback Mode will stop and allow the input message to
play back.
Volume Control
The volume is easily accessable from the front for adjustment.
Plays back up to 31 messages using Channels
1 to 5. If a message input occurs during
Binary Input/
F Priority Message playback of another message, the message
Playback Mode will stop and allow the input message to
play back.
Memory Card Slot
With an SD Card, messages can be changed while the unit is still mounted.
Optional Bracket (BK-001)
Plays back up to 5 messages using Channels
Bit Input/
1 to 5. As long as the input is held on, the
G Hold Message
message is played back, once the input is
Playback Mode
removed, the message playback stops.
This bracket is used to install the annunciator in
a place where holes have
already been drilled
for conventional
PATLITE Product
(φ133mm Type)
Plays back up to 31 messages using
Channels 1 to 5. As long as the input is held
Binary Input/
H Hold Message on, the message is played back, once the
Playback Mode input is removed, the message playback
stops.
I
Test Playback
Mode
P
□140
R5
□140
□130
Plays back Message No. 1
R5
Protrusion for positioning
Options
Wiring
PATLITE Playlist Editor 2
(Free Download)
BUSY Output:
Max. DC 40V
Max. 500mA Load
+
SD Card
(2 GB)
SDV-2GP
(OS: Windows® 2000/XP/Vista/Windows 7/Windows 8)
> The new PATLITE Playlist Editor 2 is required to
L
change the audio message data for this product.
Fuse
STOP
CH5
CH4
CH3
CH2
CH1
COM
> The SD Card does not contain any data.
Power
Supp ǐ
