EWHS
EWHS
Signal Horn
105dB at 1m
1 Channel / 32 Sounds
IP65
Cable
(Available by Special Order
NPN/PNP
Open-collector
Original wide horn design featuring a high volume
of up to 105dB (at 1m), designed for use in noisy
environments.
FEATURES
Select 1 channel from the 32 pre-recorded sounds using the built-in DIP Switch.
Enhanced for durability and safety in the work environment.
Adjustable audible sound of up to 105dB (at 1m) with volume control.
Indoor installation for upright, inverted and sideways position; upright only for outdoors.
(Do not install with the horn facing upward).
• Has the CE mark and conforms to the requirements (for 12V, 24V type) for the CE directive.
• Anti-corrosive stainless steel mounting bracket makes installation easier.
•
•
•
•
Specifications
Model
AC/DC
AC 8 - 28V
12-24V
DC 9 - 35V
EWHS -48
DC 48V
DC 35 - 60V
EWHS -100 AC 100V AC 90 - 132V
EWHS -200 AC 200V AC 180 - 260V
EWHS -24
EWHS
166
Rated
Power
Voltage Range
Voltage
Consumption
Protection
Rating
Operating
Temperature
Range
Sound
Pressure
(at 1m)
External
Contact
Capacity
105dB
5A
or more
Channel
Mass
Inputs
8W
10W
12W
13W
IP54
-200C to +600C
(IP65 by Special
85% RH or less
Order)
1.2kg
1CH
1.4kg
