IPX6= Water is sprayed for at least 3 minutes at a flow
rate of 100 L/min from a distance between
2.5m to 3.0m, and from all 360°directions
using a 12.5mm diameter jet hose nozzle.
High
Visibility
Vibration
Resistance*
RLR
IP66 TEST PROCEDURE
IP6X= The target unit is tested under-pressure in a
dust chamber for 8 hours.
High
Protection
How to Order
Model Code
Rated Voltage
04 : DC 48V
M1 : DC 12-24V
M2 : AC 90~250V
Color
R : Red
Y : Amber
RLR-04-P-R
Mounting Dimensions
G : Green
B : Blue
Blank : φ140
P : φ120
Typical Vibration Values
2G (19.6m/s2)
4.5G (44.1m/s2)
7G (68.6m/s2)
11G (107.8m/s2)
Passenger Car
Construction Machinery
Emergency Vehicle
Dump Trucks
Dimensions
Mounting Dimensions
φ162
RLR
Wire Entry Hole
φ141
0°
°
20
0
14
φ
12
0
12
φ
RLR / Bottom
40
193
Mounting Hole 3 –φ9
Nameplate
Wire Entry Hole
RLR-P / Bottom
12
26
0°
φ
12
0°
φ
20
12
65
RLR-P
0
40
(15)
3-M8
330
＋80
0
RLR-04 M1=φ6
・
RLR-M2=φ9
Mounting Hole 3 –φ9
Nameplate
(Unit: mm)
Specifications
Model
Rated Voltage
RLR-M1
RLR-04
RLR-M2
DC 12-24V
DC 48V
AC 90-250V
Operating Voltage
Range
DC 9.5V - 15V
DC 20V - 30V
AC 90V - 250V
Vibration
Resistance
Operating
Temperature Range
110m/s2
(11G)
-30 C - +70 C
2
45m/s (4.5G)
-10 C - +50 C
Dome
-R
-Y
-G
-B
(Red)
(Amber)
(Green)
(Blue)
Mass
1.0kg
1.06kg
145
