RLR
RLR
LED Revolving Warning Light
LED
Φ162
IP66
Ideal for forklift, material handling equipment and a
great variety of applications.
FEATURES
• Has the CE mark and conforms to the requirements (for 12V, 24V, 48V type) for the EC directive.
• Colors available are Red, Amber, Green, and Blue.
• RLR complies with the RoHS Directive.
LED + Brushless Motor + Bearing Mechanism
■ Long Life
The RLR has many advantages in comparison to a rotating
beacon using incandescent bulbs and the conventional
motor. The LED will last approximately 20 to 40 times
longer than an incandescent bulb, and in combination
with a brushless motor with bearings, allows the RLR
to operate from 8,000 hrs to 10,000 hrs, compared to 5,000 hrs for other rotating
beacons.
Conventional Motor Construction
Power
supply
Magnet
Shaft
Brush
Brushless Motor Construction
Power
supply
Coil
Electric circuit
Magnet
Coil
Commutator
Brush
144
Magnet
Coil
Shaft
