Revolving Warning Light
Halogen
Φ182
Large Revolving Warning Light with a solid design.
•
•
•
•
•
FEATURES
Dome is made from superior weather-resistant and light-translucent acrylic resin.
Main body is made of impact and heat resistant ABS resin.
Available Voltages are DC 12V and DC 24V.
Available Colors are Red, Amber, and Blue.
Utilizes a Halogen Bulb (Sold Separately).
Specifications
How to Order
Rated
Voltage
Model
◎
HP-12
◎
HP-24
Halogen Bulb
Bulb sold seperately
12V/24 DC
0.5A
Flash Rate Mass
(fpm)
160
HP-
1.0kg
Model
◎ Available by Special Order
Rated Voltage
12 : DC 12V
24 : DC 24V
Color
R: Red
Y: Amber
B: Blue
Dimensions
ø162
ø130
ø180
3
12
0°
60
0°
12
130
193
Mounting Dimensions
Mounting Hole 3- ø7
(Unit: mm)
141
