WH-A/WK-A
Model DEB LED Lamp
Recommended Product
WH-A/ WK-A
For more details on Model DEB
Refer to the “Replacement Bulb”
Section at the end of this Catalog
Revolving Warning Light
WH-A
Bulb
1 Alarm Sound (WHB-A Only)
90dB at 1m
IP54
Φ100
(WHB-A Only)
WK-A
Wall-mount Revolving Warning Light
featuring easy wiring with terminal block.
Easily attachable to an electrical box with easy
wiring to a terminal block.
•
•
•
•
Install in various directions when using for
•
indoor applications.
•
• Sideways
• Upside-down
•
•
•
When installing the WHB, direct the buzzer in a downward direction.
FEATURES
Has the CE mark and conforms to the requirements (12V, 24V type only) for the EC directive.
Upright, inverted, and sideways installation allowed for indoors as well as outdoors*.
Dome is made from superior weather-resistant and light-translucent acrylic resin.
Rotating parabolic reflector to enhance visibility from a distance.
Compact motor with high durability and energy-efficient characteristics.
Vibration-resistant automobile bulb for extended bulb life.
Main body is made of impact and heat resistant ABS resin.
Available Colors are Red, Amber, Green, and Blue.
Uses a terminal block for easy wiring.
*WHB installation is upright only for outdoor use.
Specifications
Dimensions
WK-12A
WH-24A
WK-24A
WH-100A
WK-100A
WH-120A
WK-120A
WH-200A
WK-200A
WKB-12A
WHB-24A
WKB-24A
WHB-100A
WKB-100A
WHB-120A
WKB-120A
WHB-200A
WKB-200A
3
80
66~84
110
Model
80
A
ø100
Mounting Dimensions
14
A
A
66
9
11.1
55
140
147
66~84
Wire Entry Hole
14.5
142
R2.1
(Unit: mm)
How to Order
WK
Model
WK-A
WH-A
Alarm
None: Without
B: With
140
-
A
Rated Voltage
12 : DC 12V
24 : DC 24V
100: AC 100V
120: AC 120V
200: AC 200V
Color
R: Red
Y: Amber
G: Green
B: Blue
Bulb
Rated
Current Flash Rate
Mass
Voltage Consumption (fpm)
Ratings Repl. No.
DC 12V
0.8A
12V 10W
9
550g
DC 24V
0.5A
24V 10W
10
AC 100V
0.07A
AC 120V
0.08A
AC 200V
0.04A
DC 12V
0.85A
DC 24V
0.5A
12V 5W
12V 10W
9
24V 10W
10
12V 5W
170
12
12
750g
550g
AC 100V
0.07A
AC 120V
AC 200V
0.04A
750g
