PEW-A/PES-A
PEW-A/ PES-A
Multi-speed Flashing Signal Light
PES-A
LED
1 Alarm Sound (PEW-B)
85dB at 1m (PEW-B)
IP55*
Φ82
PEW-A
Optional Rubber
Gasket SZ-210
NPN
Open-collector
* PEW-A: IP54 (IP23 with side-wire exit mounting)
* PES-A: IP55 with the optional rubber gasket SZ-210 (IP23 without SZ-210).
Dome shape LED Signal Light featuring enhanced
visibility and maintenance-free operation.
FEATURES
Has maintenance-free LED’s that consume nearly half the power incandescent bulb models (AC100V/200V) do.
Newly-developed triple-reflection system for enhanced visibility and low power consumption.
PEW-B type has a built-in adjustable audible alarm with a volume of up to 85dB (at 1m).
Indoor installation can be upright, inverted or sideways; Outdoors is for upright only.
The PES is rated for IP55 with the optional rubber gasket SZ-210 (IP23 without SZ-210).
Has the CE mark and conforms to the requirements for the EC directive. (for 24V type)
Is a UL Recognized Component (File No. E215660, for 24V, 120V, 230V types only).
Dome is made of superior weather resistant and light translucent acrylic resin.
Three flashing patterns of 60/120/180 fpm, switch selectable.
The PEW is rated for IP54 (IP23 with side-wire exit mounting)
Available colors are in Red, Amber, Green, and Blue.
AVAILABLE BY SPECIAL ORDER
• Body Color: Silver
• IP65: PEW type only
•
•
•
•
•
•
•
•
•
•
•
How to Order
Max.
PEW-
A
-
PES-
Model
Rated Voltage
24: AC/DC24V
100: AC 100V
120: AC 120V
200: AC 200V
230: AC 230V
120
A-
Model
Color
R: Red
Y: Amber
G: Green
B: Blue
Type
Blank : Continuous/ Flash
B : Continuous/Flashing/ Alarm
Rated Voltage
24 : AC/DC 24V
100: AC 100V
120: AC 120V
200: AC 200V
230: AC 230V
Color
R: Red
Y: Amber
G: Green
B: Blue
85dB at 1m
