NE-24
NE-24
LED Dome Signal Light
LED
IP65
Φ57
NPN/PNP
Open-collector
NE Series LED Dome Indicator Light;
The dome-shaped globe provides increased visibility while
the LEDs provide years of maintenance-free operation.
•
•
•
•
•
•
•
FEATURES
Enhanced Illumination with the use of long-life, super bright LEDs.
Low power consumption increases energy efficiency.
High vibration-resistance and unnecessary bulb replacement makes it maintenance-free.
Uses a terminal block for easy wiring.
Applications are suitable for small tooling machines, control panels, etc.
Available colors are in Red, Amber, Green, Blue, and Clear/White.
Has the CE mark and conforms to the requirements for the EC directive.
Dimensions
How to Order
Mounting Dimensions
ø57
NE 24 -
Wire Entry Hole
M16 x P1.5
37
Mounting Hole 2-ø4.5
Model
23.6
Rated Voltage
24: DC 24V
Color
R: Red
Y: Amber
G: Green
B: Blue
C: Clear/White
ø53
35.5
(Unit: mm)
Specifications
Model
NE-24-R
NE-24-Y
NE-24-G
NE-24-B
NE-24-C
118
Color
RED
AMBER
GREEN
BLUE
CLEAR/WHITE
Wiring
Rated
Voltage
Operating
Power
Consumption Temperature Mass
Range
0.63W
DC 24V
0.56W
0.53W
0.45W
-30 C - +50 C
55g
External
Contact
External
Fuse
1A
Power
Supply
(Non-polar)
