Manual Indicating Light
Complete HSST-312 Kit
HSST
HSST
LED
12 in.
Mounting Pole
& Bracket
Control Box
The HSST includes a 3-tiered LED Signal Tower kit as
a low- cost complete turn-key solution for manual
assembly factories where lean manufacturing practices
are dependent upon the overall operation efficiency.
APPLICATIONS
•
•
•
•
•
•
Assembly workstations
Safety and security applications
Call centers
Retail check stands
Hospitals
Airports
FEATURES
• Complete kit includes a 50mm diameter red, amber, green 3-tier LED Signal Tower with 4-foot Cable, poles, three-button control box, AC
power adaptor and mounting brackets that can fit onto standard cubicle partitions.
• AC power adapter (UL Listed) rated at 120VAC with 6 ft. cable length is included to allow easy set-up in any location.
• LED light illumination offers maintenance-free operation.
• Optional Extention Cable (Part No. DT-HSST-10) available in 10 ft. segments.
• Mounting screws included with the three-button control box.
• Choice of 3 in. (80mm) or 12 in. (300mm) pole included in set.
How to Order
Specifications
Model
HSST-312
Rated Voltage
HSST-312
DC 24V
Tiers
3 Tiers
(R,Y,G)
Power Supply
AC120V / DC24V
(Center Negative)
Package Description
312: Complete Kit including
- 3 button Control Box
- Control Box mounting screws
- 3 tiered Signal Tower (Red, Amber, Green)
- AC 120V Power Adaptor
- 4 ft. cable for Signal Tower
- 3 “ Pole (80mm)
- 12” Pole (300mm)
- Pole Mounting Brackets
- Instruction Manual
115
