Dimensions
Mounting Dimensions
37.5
74
Pitch
Height
30
30
1,000
30
30
20
Wire Entry Hole ø12
8.5
90
WE/WEP
Height
3 Tiers: 176
4 Tiers: 206
5 Tiers: 236
Pitch
3 Tiers: 150
4 Tiers: 180
5 Tiers: 210
4–ø4.2
(Unit: mm)
IP65 construc tion is safe for
installation in damp locations and
dusty factory environments.
How to Order
Specifications
WEP-302FB-RYG
Body Color
WE: Chrome-plated
WEP: Ivory White
Tiers
3~5
Rated Voltage
02: AC/DC 24V
Color
R: Red
Y: Amber
G: Green
B: Blue
C: Clear/White
(Top to bottom)
Stack Number
3 Tiers
4 Tiers
5 Tiers
Model
WE(P)-302
WE(P)-302FB
WE(P)-402
WE(P)-402FB
WE(P)-502
WE(P)-502FB
Rated Voltage
AC/DC 24V
Power Consumption
1.7W
2.7W
2.0W
3.2W
2.7W
3.7W
Mass
260g
300g
310g
350g
310g
350g
Type
Blank: Continuous Lighting
FB: Flashing/ Alarm
Signal Line voltage and current per LED Module
Alarm Sounds
Buzzer 1
Buzzer 2
Lead Wire Color
Purple
Skyblue
Model
Rated
Voltage
Signal Line
Voltage
WE/WEP
AC/DC 24V
AC/DC 24V
LED
Alarm
Signal Line Current Signal Line Inrush
Current
Current
R, Y
G, B, C
30mA
25mA
40mA
250mA
105
