WE/WEP
WE/WEP
Ivor y White Body
WEP Type
Signal Tower
Chrome-plated Body
WE Type
LED
2 Alarm Sounds (FB Type)
90dB at 1m (FB Type)
IP65
(FB Type: IP54)
NPN/PNP
Open-collector
Ultra slim half-moon shaped Signal Tower offers seamless
integration with most equipment.
•
•
•
•
•
•
•
•
•
•
•
FEATURES
Clear vertical-cut lens for enhanced illumination over a wide perspective.
Has an optional built-in audible alarm (FB type) with an output of 90dB (at 1m).
Installation can be vertical or horizontal.
Two body color selections of chrome plated or ivory white.
Lens made of superior impact and heat resistant polycarbonate resin for superior durability and enhanced illumination.
Both NPN and PNP Compatible for direct connection to a PLC (24V DC ONLY)
Two lighting patterns of flashing and continuous lighting.
Dust and water resistance rating of IP65 (except for FB type: IP54).
Available colors are in Red, Amber, Green, Blue, and Clear/White.
Has the CE mark and conforms to the requirements for the EC directive.
Is a UL Recognized Component (File No. E215660).
37.5mm Super-thin Design!
Conventional Design
104
Exclusively New LED Lighting Design
Model WE/WEP
Patlite has perfected a 37.5mm-thin design that significantly
enhances integration with the equipment as a built-in signal
system.
Patlite has created a revolutionary patented lighting
design in which multiple LEDs project light across a broad
peripheral area, ensuring equal intensity at the sides as well
as the front. This design, with its side-projection technology,
is a unique achievement in signal light design.
