Index
Type
Range
Air-to-water heat pumps, axial fan
With scroll or rotary compressors
38AW/80AW
30AWH
80HMA
61AF 014-019
61AF 022-105
30RQ 017-033
30RQY 017-033
30RQS 039-160
30RQSY 039-160
30RQ 182-522
Water-to-water heat pumps
With scroll compressors
61WG
With screw compressors
30XWH
30XWHV
Refrigerant
Cooling capacity,
kW
R-410A
R-410A
4.2-9
5-11.5
3-13
4-14
4-20 kW, depending on the heat pump used
14-20
21-102
16-33
17-33
15-32
17-31
38-149
42-158
37-147
42-159
175-470
181-554
74
76
78
80
82
84
86
88
90
92
273-1732
94
96
98
R-410A
R-410A
R-410A
R-410A
R-410A
R-410A
R-410A
R-410A
R-134a
R-134a
Heating capacity,
kW
29-117
317-1969
648-1932
Page
Application of the new EN14511 : 2013 chiller and heat pump performance standard:
Chiller and heat pump performances are calculated in accordance with the EN14511 : 2013 calculation standard and certified by Eurovent.
The latest version of EN14511. It uses a different method to take into account the contribution of water pumps, or heat exchanger pressure drops in the unit performances. The efficiency of the pump is no longer a default
value, but a function of the required hydraulic power. In January 2012, the Eurovent Certification Company decided that this method is more realistic and it is fully applied starting from the 2012 certification
campaign. The performances declared based on the new version of the standard were published on the ECC website www.eurovent-certification.com at the end of March 2012.
IMPORTANT: Only 2012 performances rated according the new EN14511 : 2013, taking in account water pump and heat exchanger pressure drop are certified by Eurovent. For units declared before 2012, the
previous gross EER and COP values without pump correction (for units with integral pump - measured with the pump not running) and the corresponding energy classes are available on ECC website.
Application rating conditions
Air conditioning applications (AC)
Air-cooled cooling - condition 1
Evaporator EWT/LWT 12°C/7°C
OAT 35°C
Air-cooled heating - condition 1
Condenser EWT/LWT 40°C/45°C EWT/LWT 40°C/45°C
Evaporator OAT 7°C
OAT 2°C
Water-cooled cooling - condition 1
Evaporator EWT/LWT 12°C/7°C
Condenser EWT/LWT 30°C/35°C
Water-cooled heating - condition 1
Condenser EWT/LWT 10°C/7°C
Condenser EWT/LWT 40°C/45°C
Cooling and heating floor applications (CHF)
Condition 2
Evaporator EWT/LWT 23°C/18°C
OAT 35°C
Condition 2
Condenser EWT/LWT 30°C/35°C EWT/LWT 30°C/35°C
Evaporator OAT 7°C
OAT 2°C
Condition 2
Evaporator EWT/LWT 23°C/18°C
Condenser EWT/LWT 30°C/35°C
Condition 2
Evaporator EWT/LWT 10°C/7°C
Condenser EWT/LWT 30°C/35°C
High-temperature heating (HT)
Very high-temperature heating (VHT)
Condenser EWT/LWT 47°C/55°C EWT/LWT 47°C/55°C Condenser EWT/LWT 50°C/65°C EWT/LWT 47°C/55°C
Evaporator OAT 7°C
OAT 2°C
Evaporator OAT 7°C
OAT 2°C
Evaporator EWT/LWT 10°C/7°C
Condenser EWT/LWT 47°C/55°C
Legend
EWT Entering water temperature
LWT Leaving water temperature
OAT Outdoor air temperature
73
Evaporator EWT/LWT 0°C/-3°C
Condenser EWT/LWT 47°C/55°C
