AIR-COOLED CONDENSERS/
FLUID COOLERS
Air conditioning
TENOR
Options/accessories
•
•
•
•
•
•
•
•
•
•
•
•
Multiple circuits
Special fin spacings
Mounted electrical panel
Emergency switch
Special motors (selected models)
Fan isolator switch
Stainless steel screws
Two speed connections for the
motors
EC motors for significant energy
savings
Motor power supplies 230 V-3 ph50 Hz and 400 V-3 ph-60 Hz.
Higher motor insulation for ambient
temperatures above 45°C
Alternative fin materials for saline
and polluted atmospheres
- Copper tubes/aluminium fins with
vinyl coating
- Copper tubes/aluminium fins with
a wide choice of anti-corrosion
coatings such as Blygold to suit
site conditions
09TE
Features
• The TENOR remote condensers cover a capacity range from 64 to 1915 kW
and are designed for commercial and industrial use in refrigeration and air
conditioning applications.
• The TENOR FC dry-coolers cover a capacity range from 51 to 1642 kW for use
in commercial and industrial applications, working with fluids that are copper
compatible.
• The TENOR range is designed for outdoor installation, for maximum working
temperature of 60°C and outdoor air temperature from -30°C to +45°C.
• Several fans configuration possible to match cooling capacity and sound
requirements.
• Casing in galvanised sheet steel, powder-painted polyester, resisting UV
radiation and offering excellent corrosion protection.
• The propeller fans ensure a significant sound reduction, while maintaining
high air flow performances. Motors have high-efficiency shrouds to reduce
sound levels and increase the air flow efficiency and are designed to work
with frequency speed control from 50 to 20 Hz.
• All condensers and fluid coolers are Eurovent certified and tested by
independent laboratories in accordance with European Standards. The
performances comply with EN 327 for air-cooled condensers and EN 1048 for
fluid coolers.
• Dry coolers are suitable for cooling water or other fluids that do not corrode
with copper.
• Electrical connections in weatherproof boxes, easy access.
• Air-cooled condensers are available with refrigerant R-134a, R-407C and
R-404A.
• The sound power levels are in accordance with ISO3741 and ISO3744.
68
