AIR-COOLED CONDENSERS/
FLUID COOLERS
Air conditioning
ADAGIO
Options/accessories
• Multiple circuits
• Horizontal discharge
• Extra-high feet (2 sizes) to comply
with specific site configurations
• Special fin spacings
• Mounted electrical panel
• Emergency switch
• Special motors (selected models)
• Fan isolator switch
• Sub-cooling circuits (vertical air
flow only)
• Stainless steel screws
• EC Motors for significant energy
savings (fans 630 mm diameter)
• Motor power supplies 230 V-3 ph50 Hz and 400 V-3 ph-60 Hz.
• Alternative fin materials for saline
and polluted atmospheres
- Copper tubes/aluminium fins with
vinyl coating
- Copper tubes/aluminium fins with
a wide choice of anti-corrosion
coatings such as Blygold to suit
site conditions
09AD
Features
• The ADAGIO remote condensers cover a capacity range from
6 to 316 kW designed for commercial use in refrigeration and air
conditioning applications. All models are available with vertical or horizontal
air flow.
• The ADAGIO FC dry-coolers cover a capacity range from 5 to 266 kW for use
in commercial and industrial applications, working with fluids that are copper
compatible. All models are available with vertical or horizontal air flow.
• The ADAGIO range is designed for outdoor installation, for maximum working
temperature of 55°C.
• Several fans configuration possible to match cooling capacity and sound
requirements.
• Single or double raws coils to match pressure drops requirement.
• Casing in galvanised sheet steel, resisting UV radiation and offering excellent
corrosion protection.
• The propeller fans ensure a significant sound reduction, while maintaining
high air flow performances. Motors have high-efficiency shrouds to reduce
sound levels and increase the air flow efficiency.
• All condensers and fluid coolers are Eurovent certified (excluding remote
condensers with R410A, which are out of the scope of Eurovent Certification
program) and tested by independent laboratories in accordance with
European Standards. The performances comply with EN 327 for air-cooled
condensers and EN 1048 for fluid coolers.
• Dry coolers are suitable for cooling water or other fluids that do not corrode
with copper.
• Electrical connections in weatherproof boxes, easy access for maintenance.
• Air-cooled condensers are available with refrigerant R-134a, R-407C, R-410A.
and R-404A.
• The sound power levels are in accordance with ISO 3741 and ISO 3744.
66
