Water-Cooled/Condenserless
Liquid Chillers with Integrated
Hydronic Module
Air conditioning
30RW
Options
• High-pressure single or dual pump,
evaporator
• Condenser hydronic module with
variable-speed single or dual pump
• Heat pump (hot-water control)
• Electronic starter for reduced startup current
• RS485 communications and “CCN
Clock Board” time schedule board
• Very low temperature glycol solution
down to -10°C
• Field water connections at the unit
top
Features
• Ten sizes with nominal cooling capacities from 109 to 315 kW.
• Aquasnap chillers with scroll compressors, digital auto-adaptive Pro-Dialog
control and ozone-friendly refrigerant HFC-407C.
• Can be supplied with integrated hydronic evaporator and condenser modules,
limiting the installation to simple operations such as the entering and leaving
water piping connection.
• Intelligent control of condenser water pump speed and operation of glycol
cooler (30RW) or air-cooled condenser fans (30RWA) to ensure reliable and
economical operation.
• Quick electrical connections.
• Units can operate down to -20°C outside temperature.
• The variable-speed condenser water pump automatically adjusts the water
flow rate to maintain the ideal condensing conditions.
• High-performance plate heat exchangers maximise the thermodynamic
properties of refrigerant HFC-407C. From size 30RW 160 the evaporator and
the condenser have two interlaced refrigerant circuits.
• Space-saving design.
• No plant room required – unit can be installed in a place that is open to the
public, if local regulations permit.
• The refrigerant circuit is completely leak-proof.
• Used with Carrier 09 series glycol coolers or air-cooled condensers, supplied
ready for installation with a control box. All control components are installed
and tested in the factory.
Water cooled mono circuit
A
A
Pro-Dialog Plus operator interface
