30WG/30WGA
Physical data
30WG/30WGA
020
025
030
Air conditioning application as per EN14511-3: 2013 - 30WG
kW
24.6
28.7
31.5
Nominal cooling capacity
kW
4.72
4.72
4.69
EER
Eurovent class
B
B
B
ESEER
kW/kW
5.10
5.09
5.03
Part load performance ESEER
kW/kW
5.35
5.35
5.30
Air conditioning application as per EN14511-3: 2013 - 30WGA
kW
22.6
27.0
29.5
Nominal cooling capacity
kW
3.75
3.84
3.87
EER
kg
191/164
200/171
200/171
Operating weight 30WG/30WGA*
Hermetic scroll 48.3 r/s
Compressors
Quantity
1
1
1
Number of capacity stages
1
1
1
Minimum capacity
%
100
100
100
Dimensions, standard unit**
Width x depth x height
mm
600 x 1044 x 901
R-410A
Refrigerant*
Pro-Dialog+
Control
Direct-expansion plate heat exchanger
Evaporator
Plate heat exchanger
Condenser (30WG only)
035
040
045
050
060
070
080
090
36.7
4.73
B
5.05
5.32
41.8
4.69
B
5.03
5.32
46.6
4.72
B
5.07
5.36
58.1
4.72
B
5.83
6.31
63.4
4.65
B
5.90
6.38
73.8
4.69
B
5.79
6.30
83.9
4.65
B
5.99
6.54
94.6
4.68
B
5.93
6.44
34.7
3.93
207/177
39.2
3.94
212/180
43.7
3.90
220/185
53.7
3.82
386/321
59.8
3.85
392/324
69.2
3.86
403/332
78.3
3.91
413/339
87.8
3.88
441/354
1
1
100
1
1
100
1
1
100
2
2
50
2
2
50
2
2
50
2
2
50
2
2
50
880 x 1474 x 901
NOTE: For the conditions, please refer to page 31. 30WGA performance are given for an equivalent refrigerant piping length (without filter drier and valves) of 3 m.
*
Weight shown is a guideline only. To find out the unit refrigerant charge, please refer to the unit nameplate.
** The dimensions shown are for the standard unit. For other unit types please refer to the dimensional drawings.
Electrical data
30WG/30WGA
Power circuit
Nominal voltage
Control circuit supply
Maximum start-up current draw (Un)*
Standard unit, 30WG
Standard unit, 30WGA
Unit with electronic starter option, 30WG
Unit with electronic starter option, 30WGA
Maximum operating power input, 30WG**
Maximum operating power input, 30WGA**
Maximum operating current draw (Un), 30WG***
Maximum operating current draw (Un), 30WGA***
020
025
030
V-ph-Hz
98
98
53.9
53.9
9.1
8.7
15.6
14.7
040
045
050
060
070
080
090
147
147
80.9
80.9
13.6
12.5
23.2
21.7
158
158
86.9
86.9
15
14.2
25.4
24.1
197
197
108.4
108.4
17
16.1
29
27.5
163
160.7
100.1
96.8
21.4
20.4
37.4
35.4
165
161.8
102.1
97.9
23.4
22.6
39.6
38.7
174
170.2
108.9
104.1
27.2
25.0
46.4
43.5
188
183.4
117.9
112.3
30
28.5
50.8
48.1
233
226
144.4
137.4
34
32.2
58
55.0
400-3-50 ± 10%
24 V, via internal transformer
A
A
A
A
kW
kW
A
A
035
142
142
78.1
78.1
10.7
10.2
18.7
17.7
142
142
78.1
78.1
11.7
11.3
19.8
19.3
*
Maximum instantaneous start-up current at operating limit values (maximum operating current of the smallest compressor(s) + fan current + locked rotor current of the largest compressor).
** Maximum power input at the unit operating limits.
*** Maximum unit operating current at maximum unit power input and 400 V.
Operating range
65
65
60
55
Condensing temperature, °C
Condenser leaving water temperature, °C
30WG 30WGA
50
45
40
Option 6
Standard
35
30
25
20
15
60
55
50
45
Medium
temperature
application
40
35
Standard
30
25
-14 -12 -10 -8 -6 -4 -2
0
2
4
6
20
8 10 12 14 16 18 20
-2
Evaporator leaving water temperature, °C
30WG standard unit
30WG unit with option 6 (brine)
Option 6: Very low-temperature glycol solution
0
2
4
6
8
10
12
14
Evaporator leaving water temperature, °C
30WGA standard unit
30WGA unit for medium temperature application (% glycol < 25%)
55
16
18
20
